2.5.0 INTRODUCTION

Getting Started

Install CFWheels and get a local development server running

By far the quickest way to get started with CFWheels is via . CommandBox brings a whole host of command line capabilities to the CFML developer. It allows you to write scripts that can be executed at the command line written entirely in CFML. It allows you to start a CFML server from any directory on your machine and wire up the code in that directory as the web root of the server. What's more is, those servers can be either Lucee servers or Adobe ColdFusion servers. You can even specify what version of each server to launch. Lastly, CommandBox is a package manager for CFML. That means you can take some CFML code and package it up into a module, host it on ForgeBox.io, and make it available to other CFML developers. In fact we make extensive use of these capabilities to distribute CFWheels plugins and templates. More on that later.

One module that we have created is a module that extends CommandBox itself with commands and features specific to the CFWheels framework. The CFWheels CLI module for CommandBox is modeled after the Ruby on Rails CLI module and gives similar capabilities to the CFWheels developer.

Install CommandBox

The first step is to get downloaded and running. CommandBox is available for Windows, Mac & Linux, and can be installed manually or using one of the respective package managers for each OS. You can use on Windows, on MacOS, or Yum/Apt on Linux depending on your flavor of Linux. Please follow the instructions on how to install CommandBox on your particular operating system. At the end of the installation process you want to make sure the box command is part of your system path so you can call the command from any directory on your system.

Once installed, you can either double-click on the box executable which opens the CommandBox shell window, or run box from a CMD window in Windows, Terminal window in MacOS, or shell prompt on a Linux server. Sometimes you only want to call a single CommandBox command and don't need to launch a whole CommandBox shell window to do that, for these instances you can call the CommandBox command directly from your default system terminal window by prefixing the command with the box prefix.

So to run the CommandBox version command you could run box version from the shell or you could launch the CommandBox shell and run version inside it.

box version

version

This is a good concept to grasp, cause depending on your workflow, you may find it easier to do one versus the other. Most of the commands you will see in these CLI guides will assume that you are entering the command in the actual CommandBox shell so the box prefix is left off.

Install the cfwheels-cli CommandBox Module

Okay, now that we have CommandBox installed, let's add the CFWheels CLI module.

install cfwheels-cli

Installing this module will add a number of commands to your default CommandBox installation. All of these commands are prefixed by the wheels name space. There are commands to create a brand new CFWheels application or scaffold out sections of your application. We'll see some of these commands in action momentarily.

Start a new Application

Now that we have CommandBox installed and extended it with the CFWheels CLI module, let's start our first CFWheels app from the command line. We'll look at the simplest method for creating a CFWheels app and starting our development server.

wheels generate app myApp server start

A few minutes after submitting the above commands a new browser window should open up and display the default CFWheels congratulations screen.

So what just happened? Since we only passed the application name myApp to the wheels generate app command, it used default values for most of its parameters and downloaded our Base template (cfwheels-base-template) from ForgeBox.io, then downloaded the framework core files (cfwheels) from ForgeBox.io and placed it in the wheels directory, then configured the application name and reload password, and started a Lucee server on a random port.

A Word About Command Aliases

CommandBox commands have the capability to be called by multiple names or aliases. The command above wheels generate app can also be initiated by typing wheels g app. In fact g is an alias for generate so wherever you see a command in the CLI documentation that has generate in it you can substitute g instead.

In addition to shortening generate to g, aliases can completely change the name space as well. A command that you haven't seen yet is the wheels generate app-wizard command. This command guides the user through a series of menu options, building up all the parameters needed to customize the start of a new CFWheels project. You're likely to use the wizard when starting a new CFWheels application so it's good to become familiar with it.

This command has the normal alias referenced above at wheels g app-wizard but it also has an additional alias at wheels new which is the command more prevalent in the Rails community. So the three commands wheels generate app-wizard, wheels g app-wizard, and wheels new all call the same functionality which guides the user though a set of menus, collecting details on how to configure the desired app. Once all the parameters have been gathered, this command actually calls the wheels generate app command to create the actual CFWheels application.

This getting started guide has taken you from the very beginning and gotten you to the point where you can go into any empty directory on your local development machine and start a CFWheels project by issuing a couple of CLI commands. In later guides we'll explore these options further and see what else the CLI can do for us.

Running Local Development servers

Starting a local development server

With CommandBox, we don't need to have Lucee or Adobe ColdFusion installed locally. With a simple command, we can make CommandBox go and get the CFML engine we've requested, and quickly create a server running on Undertow. Make sure you're in the root of your website, and then run:

server start

The server will then start on a random port on 127.0.0.1 and will create a server.json file in your webroot. We can add various options to server.json to customize our server. Here's an example:

{
    "name":"myApp",
    "force":true,
    "web":{
        "http":{
            "port":60000
        },
        "rewrites":{
            "enable":true,
            "config":"urlrewrite.xml"
        }
    }
}

In this example, I've set the server name to myApp, meaning I can now start the server from any directory by simply calling start myApp. I've also specified a specific port, 60000, but you can specify any port you want, or just remove that to start on a random port each time. Lastly, I've enabled URL rewriting, and pointing the URL rewrite configuration file to the urlrewrite.xml which is included in CFWheels 2.x. (If you've used the wheels new command to create your app, this will already be done for you).

Using custom host names

You can also specify hosts other than localhost: there's a useful CommandBox module to do that (Host updater) which will automatically create entries in your hosts file to allow for domains such as myapp.local running on port 80. You can install it via install commandbox-hostupdater when running the box shell with administrator privileges.

Controlling local servers

Obviously, anything you start, you might want to stop. Servers can be stopped either via right/ctrl clicking on the icon in the taskbar, or by the stop command. To stop a server running in the current directory issue the following:

server stop

You can also stop a server from anywhere by using its name:

server stop myApp

If you want to see what server configurations exist on your system and their current status, simply do server list

server list

myapp (stopped)
 http://127.0.0.1:60000
 Webroot: /Users/cfwheels/Documents/myapp

myAPI (stopped)
 http://127.0.0.1:60010
 Webroot: /Users/cfwheels/Documents/myAPI

megasite (stopped)
 http://127.0.0.1:61280
 CF Engine: lucee 4.5.4+017
 Webroot: /Users/cfwheels/Documents/megasite

awesomesite (stopped)
 http://127.0.0.1:60015
 CF Engine: lucee 4.5.4+017
 Webroot: /Users/cfwheels/Documents/awesomeo

To remove a server configuration from the list, you can use server forget myapp. Note the status of the servers on the list are somewhat unreliable, as it only remembers the last known state of the server: so if you start a server and then turn off your local machine, it may still remember it as running when you turn your local machine back on, which is why we recommend the use of force: true in the server.json file.

Specifying different CF engines

By default, CommandBox will run Lucee (version 5.x at time of writing). You may wish to specify an exact version of Lucee, or use Adobe ColdFusion. We can do this via either setting the appropriate cfengine setting in server.json, or at runtime with the cfengine= argument.

Start the default engine

CommandBox> start

Start the latest stable Lucee 5.x engine

CommandBox> start cfengine=lucee@5

Start a specific engine and version

CommandBox> start cfengine=adobe@10.0.12

Start the most recent Adobe server that starts with version "11"

CommandBox> start cfengine=adobe@11

Start the most recent adobe engine that matches the range

CommandBox> start cfengine="adobe@>9.0 <=11"

Or via server.json

{
    "name":"myApp",
    "force":true,
    "web":{
        "http":{
            "host":"localhost",
            "port":60000
        },
        "rewrites":{
            "enable":true,
            "config":"urlrewrite.xml"
        }
    },
    "app":{
        "cfengine":"adobe@2016"
    },
}

CFIDE / Lucee administrators

The default username and password for all administrators is admin & commandbox

You can of course run multiple servers, so if you need to test your app on Lucee 4.x, Lucee 5.x and Adobe 2016, you can just start three servers with different cfengine= arguments!

Watch out

CommandBox 5.1 required to install dependencies easily

By default the Lucee server that CommandBox starts has all the basic Lucee extensions that you are going to need installed, but if need to minimize the size of the Lucee instance you launch, then you can use Lucee-Light by specifying cfengine=lucee-light in your server.json file. CFWheels can run just fine on lucee-light (which is after all, Lucee, minus all the extensions) but at a minimum, requires the following extensions to be installed as dependencies in your box.json. Please note you may have to add any drivers you need for your database to this list as well.

"dependencies":{
    "lucee-image":"lex:https://ext.lucee.org/lucee.image.extension-1.0.0.35.lex",
    "lucee-zip": "lex:https://ext.lucee.org/compress-extension-1.0.0.2.lex",
    "lucee-esapi": "lex:https://ext.lucee.org/esapi-extension-2.1.0.18.lex"
}

Once added to your box.json file, while the server is running, just do box install, which will install the dependencies, and load them into the running server within 60 seconds.

Alternatively you can download the extensions and add them manually to your server root's deploy folder (i.e \WEB-INF\lucee-server\deploy)

Beginner Tutorial: Hello World

In this tutorial, we'll be writing a simple application to make sure we have CFWheels installed properly and that everything is working as it should.

Testing Your Install

Let's make sure we're all on the same page. I'm going to assume that you've followed the guide and have CommandBox all setup. If you haven't done that, stop and read that guide get everything setup. It's okay, this web page will wait for you.

Okay, so you have CFWheels installed and can see the CFWheels "Congratulations!" page as shown below. That wasn't that hard now, was it?

Hello World: Your First CFWheels App

Okay, let's get to some example code. We know that you've been dying to get your hands on some code!

To continue with Programming Tutorial Tradition, we'll create the ubiquitous Hello World! application. But to keep things interesting, let's add a little CFWheels magic along the way.

Setting up the Controller

Let's create a controller from scratch to illustrate how easy it is to set up a controller and plug it into the CFWheels framework.

First, create a file called Say.cfc in the controllers directory and add the code below to the file.

controllers/Say.cfc

component extends="Controller"{
}

Congratulations, you just created your first CFWheels controller! What does this controller do, you might ask? Well, to be honest, not much. It has no methods defined, so it doesn't add any new functionality to our application. But because it extends the base Controller component, it inherits quite a bit of powerful functionality and is now tied into our CFWheels application.

So what happens if we try to call our new controller right now? Lets take a look. Open your browser and point your browser to the new controller. Because my local server is installed on port 60000, my URL is http://127.0.0.1:60000/say. You may need to enter a different URL, depending on how your web server is configured. In my case, I'm using CommandBox.

The error says "Could not find the view page for the 'index' action in the 'say' controller." Where did "index" come from? The URL we typed in only specified a controller name but no action. When an action is not specified in the URL, CFWheels assumes that we want the default action. Out of the box, the default action in CFWheels is set to index. So in our example, CFWheels tried to find the index action within the say controller, and it threw an error because it couldn't find its view page.

Setting up an Action

But let's jump ahead. Now that we have the controller created, let's add an action to it called hello. Change your say controller so it looks like the code block below:

controllers/Say.cfc

component extends="Controller" {
    function hello() {
    }
}

As you can see, we created an empty method named hello.

Now let's call our new action in the browser and see what we get. To call the hello action, we simply add /hello to the end of the previous URL that we used to call our say controller:

http://127.0.0.1:60000/say/hello

Once again, we get a ColdFusion error. Although we have created the controller and added the hello action to it, we haven't created the view.

Setting up the View

By default, when an action is called, CFWheels will look for a view file with the same name as the action. It then hands off the processing to the view to display the user interface. In our case, CFWheels tried to find a view file for our say/hello action and couldn't find one.

Let's remedy the situation and create a view file. View files are simple CFML pages that handle the output of our application. In most cases, views will return HTML code to the browser. By default, the view files will have the same name as our controller actions and will be grouped into a directory under the view directory. This new directory will have the same name as our controller.

Find the views directory in the root of your CFWheels installation. There will be a few directories in there already. For now, we need to create a new directory in the views directory called say. This is the same name as the controller that we created above.

Now inside the say directory, create a file called hello.cfm. In the hello.cfm file, add the following line of code:

views/say/hello.cfm

<h1>Hello World!</h>

Save your hello.cfm file, and let's call our say/hello action once again. You have your first working CFWheels page if your browser looks like Figure 3 below.

You have just created your first functional CFWheels page, albeit it is a very simple one. Pat yourself on the back, go grab a snack, and when you're ready, let's go on and extend the functionality of our Hello World! application a little more.

Adding Dynamic Content to Your View

We will add some simple dynamic content to our hello action and add a second action to the application. We'll then use some CFWheels code to tie the 2 actions together. Let's get get to it!

The Dynamic Content

The first thing we are going to do is to add some dynamic content to our say/hello action. Modify your say controller so it looks like the code block below:

controllers/Say.cfc

component extends="Controller" {
    function hello() {
        time = Now();
    }
}

All we are doing here is creating a variable called time and setting its value to the current server time using the basic ColdFusion Now() function. When we do this, the variable becomes immediately available to our view code.

Why not just set up this value directly in the view? If you think about it, maybe the logic behind the value of time may eventually change. What if eventually we want to display its value based on the user's time zone? What if later we decide to pull it from a web service instead? Remember, the controller is supposed to coordinate all of the data and business logic, not the view.

Displaying the Dynamic Content

Next, we will modify our say/hello.cfm view file so that it looks like the code block bellow. When we do this, the value will be displayed in the browser.

views/say/hello.cfm

<h1>Hello World!</h1>
<p>Current time: <cfoutput>#time#</cfoutput></p>

call your say/hello action again in your browser. Your browser should look like Figure 4 below.

This simple example showed that any dynamic content created in a controller action is available to the corresponding view file. In our application, we created a time variable in the say/hello controller action and display that variable in our say/hello.cfm view file.

Adding a Second Action: Goodbye

Now we will expand the functionality of our application once again by adding a second action to our say controller. If you feel adventurous, go ahead and add a goodbye action to the say controller on your own, then create a goodbye.cfm view file that displays a "Goodbye" message to the user. If you're not feeling that adventurous, we'll quickly go step by step.

First, modify the the say controller file so that it looks like the code block below.

controllers/Say.cfc

component extends="Controller" {
    function hello() {
        time = Now();
    }

    function goodbye() {
    }
}

Now go to the views/say directory and create a goodbye.cfm page.

Add the following code to the goodbye.cfm page and save it.

views/say/goodbye.cfm

Goodbye World!

If we did everything right, we should be able to call the new say/goodbye action using the following URL:

http://127.0.0.1:60000/say/goodbye

Your browser should look like Figure 5 below:

Linking to Other Actions

Now let's link our two actions together. We will do this by adding a link to the bottom of each page so that it calls the other page.

Linking Hello to Goodbye

Open the say/hello.cfm view file. We are going to add a line of code to the end of this file so our say/hello.cfm view file looks like the code block below:

views/say/hello.cfm

<h1>Hello World!</h1>
<p>Current time: <cfoutput>#time#</cfoutput></p>
<p>Time to say <cfoutput>#linkTo(text="goodbye", action="goodbye")#?</cfoutput></p>

The linkTo() function is a built-in CFWheels function. In this case, we are passing 2 named parameters to it. The first parameter, text, is the text that will be displayed in the hyperlink. The second parameter, action, defines the action to point the link to. By using this built-in function, your application's main URL may change, and even controllers and actions may get shifted around, but you won't suffer from the dreaded dead link. CFWheels will always create a valid link for you as long as you configure it correctly when you make infrastructure changes to your application.

Once you have added the additional line of code to the end of the say/hello.cfm view file, save your file and call the say/hello action from your browser. Your browser should look like Figure 6 below.

You can see that CFWheels created a link for us and added an appropriate URL for the say/goodbye action to the link.

Linking Goodbye to Hello

Let's complete our little app and add a corresponding link to the bottom of our say/goodbye.cfm view page.

Open your say/goodbye.cfm view page and modify it so it looks like the code block below.

CFML: views/say/goodbye.cfm

views/say/goodbye.cfm

<h1>Goodbye World!</h1>
<p>Time to say <cfoutput>#linkTo(text="hello", action="hello")#?</cfoutput></p>

If you now call the say/goodbye action in your browser, your browser should look like Figure 7 below.

Much More to Learn

You now know enough to be dangerous with CFWheels. Look out! But there are many more powerful features to cover. You may have noticed that we haven't even talked about the M in MVC.

No worries. We will get there. And we think you will enjoy it.

Beginner Tutorial: Hello Database

A quick tutorial that demonstrates how quickly you can get database connectivity up and running with CFWheels.

CFWheels's built in model provides your application with some simple and powerful functionality for interacting with databases. To get started, you will make some simple configurations, call some functions within your controllers, and that's it. Best yet, you will rarely ever need to write SQL code to get those redundant CRUD tasks out of the way.

Our Sample Application: User Management

We'll learn by building part of a sample user management application. This tutorial will teach you the basics of setting up a resource that interacts with the CFWheels ORM.

Download source code

You can download all the source code for this sample application from

Setting up the Data Source

By default, CFWheels will connect to a data source that has the same name as the folder containing your application. So if your application is in a folder called C:\websites\mysite\blog\, then it will connect to a data source named blog.

To change this default behavior, open the file at config/settings.cfm. In a fresh install of CFWheels, you'll see some commented-out lines of code that read as such:

Uncomment the lines that tell CFWheels what it needs to know about the data source and provide the appropriate values. This may include values for dataSourceName, dataSourceUserName, and dataSourcePassword.

Our Sample Data Structure

CFWheels supports MySQL, SQL Server, PostgreSQL, and H2. It doesn't matter which DBMS you use for this tutorial; we will all be writing the same CFML code to interact with the database. CFWheels does everything behind the scenes that needs to be done to work with each DBMS.

That said, here's a quick look at a table that you'll need in your database, named users:

Note a couple things about this users table:

The table name is plural.
The table has an auto-incrementing primary key named id.

Fortunately, there are ways of going outside of these conventions when you really need it. But let's learn the conventional way first. Sometimes you need to learn the rules before you can know how to break them.

Creating Routes for the users Resource

Next, open the file at config/routes.cfm. You will see contents similar to this:

We are going to create a section of our application for listing, creating, updating, and deleting user records. In CFWheels routing, this requires a plural resource, which we'll name users.

Because a users resource is more specific than the "generic" routes provided by CFWheels, we'll list it first in the chain of mapper method calls:

This will create URL endpoints for creating, reading, updating, and deleting user records:

Name is referenced in your code to tell CFWheels where to point forms and links.
Method is the HTTP verb that CFWheels listens for to match up the request.
URL Path is the URL that CFWheels listens for to match up the request.

Don't forget to reload

You will need to reload your application after adding new routes!

Creating Users

First, let's create a simple form for adding a new user to the users table. To do this, we will use CFWheels's form helper functions. CFWheels includes a whole range of functions that simplifies all of the tasks that you need to display forms and communicate errors to the user.

Creating the Form

Now create a new file in views/users called new.cfm. This will contain the view code for our simple form.

Next, add these lines of code to the new file:

Form Helpers

What we've done here is use form helpers to generate all of the form fields necessary for creating a new user in our database. It may feel a little strange using functions to generate form elements, but it will soon become clear why we're doing this. Trust us on this one… you'll love it!

Supplying the Form with Data

All of the form helper calls in our view specify an objectName argument with a reference to a variable named user. That means that we need to supply our view code with an object called user. Because the controller is responsible for providing the views with data, we'll set it there.

Create a new ColdFusion component at controllers/Users.cfc.

CFWheels will automatically know that we're talking about the users database table when we instantiate a usermodel. The convention: database tables are plural and their corresponding CFWheels models are singular.

Why is our model name singular instead of plural? When we're talking about a single record in the users database, we represent that with an individual model object. So the users table contains many user objects. It just works better in conversation.

The Generated Form

Now when we run the URL at http://localhost/users/new, we'll see the form with the fields that we defined.

The HTML generated by your application will look something like this:

So far we have a fairly well-formed, accessible form, without writing a bunch of repetitive markup.

Handling the Form Submission

Next, we'll code the create action in the controller to handle the form submission and save the new user to the database.

Because we used the objectName argument in the fields of our form, we can access the user data as a struct in the params struct.

There are more things that we can do in the create action to handle validation, but let's keep it simple in this tutorial.

Listing Users

First, let's get the data that the listing needs. Create an action named index in the users controller like so:

In the view at views/users/index.cfm, it's as simple as looping through the query and outputting the data

When to use EncodeForHtml

You'll see references to EncodeForHtml in some of our examples that output data. This helps escape HTML code in data that attackers could use to embed inject harmful JavaScript. (This is commonly referred to as an "XSS attack," short for "Cross-site Scripting attack.")

A rule of thumb: you do not need to use EncodeForHtml when passing values into CFWheels helpers like linkTo, buttonTo, startFormTag, textField, etc. However, you need to escape data that is displayed directly onto the page without a CFWheels helper.

Editing Users

We'll now show another cool aspect of form helpers by creating a screen for editing users.

Coding the Edit Form

You probably noticed in the code listed above that we'll have an action for editing a single users record. We used the linkTo() form helper function to add an "Edit" button to the form. This action expects a key as well.

Because in the linkTo() form helper function we specified the parameter key, Wheels adds this parameter into the URL when generating the route.

Wheels will automatically add the provided 'key' from the URL to the params struct in the controllers edit() function.

Given the provided key, we'll have the action load the appropriate user object to pass on to the view:

The view at views/user/edit.cfm looks almost exactly the same as the view for creating a user:

But an interesting thing happens. Because the form fields are bound to the user object via the form helpers' objectName arguments, the form will automatically provide default values based on the object's properties.

With the user model populated, we'll end up seeing code similar to this:

Pretty cool, huh?

Opportunities for Refactoring

There's a lot of repetition in the new and edit forms. You'd imagine that we could factor out most of this code into a single view file. To keep this tutorial from becoming a book, we'll just continue on knowing that this could be better.

Handing the Edit Form Submission

Now we'll create the update action. This will be similar to the create action, except it will be updating the user object:

Deleting Users

Notice in our listing above that we have a delete action. Here's what it would look like:

Database Says Hello

We've shown you quite a few of the basics in getting a simple user database up and running. We hope that this has whet your appetite to see some of the power packed into the CFWheels framework. There's plenty more.

Be sure to read on to some of the related chapters listed below to learn more about working with CFWheels's ORM.

Tutorial: CFWheels, AJAX, and You

Using CFWheels to develop web applications with AJAX features is a breeze. You have several options and tools at your disposal, which we'll cover in this chapter.

CFWheels was designed to be as lightweight as possible, so this keeps your options fairly open for developing AJAX features into your application.

While there are several flavors of JavaScript libraries out there with AJAX support, we will be using the in this tutorial. Let's assume that you are fairly familiar with the basics of jQuery and know how to set it up.

For this tutorial, let's create the simplest example of all: a link that will render a message back to the user without refreshing the page.

A Simple Example

In this example, we'll wire up some simple JavaScript code that calls a CFWheels action asynchronously. All of this will be done with basic jQuery code and built-in CFWheels functionality.

First, let's make sure we've got an appropriate route setup. It might be you're still using the default wildcard() route which will create some default GET routes for the controller/action pattern, but we'll add a new route here just for practice:

Then, let's create a link to a controller's action in a view file, like so:

That piece of code by itself will work just like you expect it to. When you click the link, you will load the hello action inside the say controller.

With that code, we are listening to the click event of the hyperlink, which will make an asynchronous request to the hello action in the say controller. Additionally, the JavaScript call is passing a URL parameter called format set to json.

Note that the success block inserts keys from the response into the empty h1 and p blocks in the calling view. (You may have been wondering about those when you saw the first example. Mystery solved.)

Lastly, notice the lines where we're setting greeting["message"] and greeting["time"]. Due to the case-insensitive nature of ColdFusion, we recommend setting variables to be consumed by JavaScript using bracket notation like that. If you do not use that notation (i.e., greetings.message and greetings.time instead), your JavaScript will need to reference those keys from the JSON as MESSAGE and TIME (all caps). Unless you like turning caps lock on and off, you can see how that would get annoying after some time.

Assuming you already included jQuery in your application and you followed the code examples above, you now have a simple AJAX-powered web application built on Wheels. After clicking that Alert me! link, your say controller will respond back to you the serialized message via AJAX. jQuery will parse the JSON object and populate the h1 and pwith the appropriate data.

AJAX in CFWheels Explained

That is it! Hopefully now you have a clearer picture on how to create AJAX-based features for your web applications.

Frameworks and CFWheels

Learn the goals of CFWheels as well as web development frameworks in general. Then learn more about some key concepts in CFWheels.

This chapter will introduce you to frameworks in general and later specifically to CFWheels. We'll help you decide if you even need a framework at all and what common problems a framework tries to solve. If we're able to convince you that using a framework is the right thing for you, then we'll present our goals with creating CFWheels and show you some key CFWheels concepts.

So let's get started.

Do I Really Need to Use a Framework?

Short answer, no. If you don't mind doing the same thing over and over again and are getting paid by the hour to do so, then by all means keep doing that.

Slightly longer answer, no. If you're working on a highly customized project that does not fall within what 9 out of 10 web sites/applications normally do then you likely need a high percentage of custom code, and a framework will not help much.

However, if you're like most of us and have noticed that for every new project you start on--or even every new feature you add to an existing project--you waste a lot of time re-creating the wheel, then you should read on because CFWheels may just be the solution for you!

CFWheels will make starting a new project or building a new feature quick and painless. You can get straight to solving business problems on day one! To understand how this is achieved, we figured that a little background info on frameworks in general may help you out.

All good frameworks rise from the need to solve real problems in real world situations. CFWheels is based heavily on the Rails framework for Ruby and also gets inspiration from Django and, though to a lesser extent, other frameworks in the ColdFusion space (like Fusebox, for example). Over the years the contributors to these frameworks have identified problems and tedious tasks in their own development processes, built a solution for it, and abstracted (made it more generic so it suits any project) the solution into the framework in question. Piggy-backing on what all these great programmers have already created and adding a few nice solutions of our own, CFWheels stands on solid ground.

OK, so that was the high level overview of what frameworks are meant to do. But let's get a little more specific.

Framework Goals in General

Most web development frameworks set out to address some or all of these common concerns:

Map incoming requests to the code that handles them.
Separate your business logic from your presentation code.
Let you work at a higher level of abstraction, thus making you work faster.
Give you a good code organization structure to follow.
Encourage clean and pragmatic design.
Simplify saving data to a storage layer.

Like all other good frameworks, CFWheels does all this. But there are some subtle differences, and certain things are more important in CFWheels than in other frameworks and vice versa. Let's have a look at the specific goals with CFWheels so you can see how it relates to the overall goals of frameworks in general.

Our Goals With CFWheels

As we've said before, CFWheels is heavily based on Ruby on Rails, but it's not a direct port, and there are some things that have been changed to better fit the CFML language. Here's a brief overview of the goals we're striving for with CFWheels (most of these will be covered in greater detail in later chapters):

Simplicity

We strive for simplicity on a lot of different levels in CFWheels. We'll gladly trade code beauty in the framework's internal code for simplicity for the developers who will use it. This goal to keep things simple is evident in a lot of different areas in CFWheels. Here are some of the most notable ones:

The concept of object oriented programming is very simple and data-centric in CFWheels, rather than 100% "pure" at all times.
By default, you'll always get a query result set back when dealing with multiple records in CFWheels, simply because that is the way we're all used to outputting data.
CFWheels encourages best practices, but it will never give you an error if you go against any of them.
With CFWheels, you won't program yourself into a corner. If worse comes to worse, you can always drop right out of the framework and go back to old school code for a while if necessary.
Good old CFML code is used for everything, so there is no need to mess with XML for example.

What this means is that you don't have to be a fantastic programmer to use the framework (although it doesn't hurt). It's enough if you're an average programmer. After using CFWheels for a while, you'll probably find that you've become a better programmer though!

Documentation

If you've ever downloaded a piece of open source software, then you know that most projects lack documentation. CFWheels hopes to change that. We're hoping that by putting together complete, up-to-date documentation that this framework will appeal, and be usable, by everyone. Even someone who has little ColdFusion programming background, let alone experience with frameworks.

Key Wheels Concepts

Besides what is already mentioned above, there are some key concepts in CFWheels that makes sense to familiarize yourself with early on. If you don't feel that these concepts are to your liking, feel free to look for a different framework or stick to using no framework at all. Too often programmers choose a framework and spend weeks trying to bend it to do what they want to do rather than follow the framework conventions.

Speaking of conventions, this brings us to the first key concept:

Convention Over Configuration

Instead of having to set up tons of configuration variables, CFWheels will just assume you want to do things a certain way by using default settings. In fact, you can start programming a Wheels application without setting any configuration variables at all!

If you find yourself constantly fighting the conventions, then that is a hint that you're not yet ready for CFWheels or CFWheels is not ready for you.

Beautiful Code

Beautiful (for lack of a better word) code is code that you can scan through and immediately see what it's meant to do. It's code that is never repeated anywhere else. And, most of all, it's code that you'll enjoy writing and will enjoy coming back to 6 months from now.

Sometimes the CFWheels structure itself encourages beautiful code (separating business logic from request handling, for example). Sometimes it's just something that comes naturally after reading documentation, viewing other CFWheels applications, and talking to other CFWheels developers.

Model-View-Controller (MVC)

If you've investigated frameworks in the past, then you've probably heard this terminology before. Model-View-Controller, or MVC, is a way to structure your code so that it is broken down into three easy-to-manage pieces:

Model: Just another name for the representation of data, usually a database table.
View: What the user or their browser sees and interacts with (a web page in most cases).
Controller: The behind-the-scenes guy that's coordinating everything.

"Uh, yeah. So what's this got to do with anything?" you may ask. MVC is how CFWheels structures your code for you. As you start working with CFWheels applications, you'll see that most of the code you write (database queries, forms, and data manipulation) are very nicely separated into one of these three categories.

The benefits of MVC are limitless, but one of the major ones is that you almost always know right where to go when something needs to change.

If you've added a column to the vehicles table in your database and need to give the user the ability to edit that field, all you need to change is your View. That's where the form is presented to the user for editing.

If you find yourself constantly getting a list of all the red cars in your inventory, you can add a new method to your model called getRedCars() that does all the work for you. Then when you want that list, just add a call to that method in your controller and you've got 'em!

Object Relational Mapping (ORM)

The Object Relational Mapping, or ORM, in CFWheels is perhaps the one thing that could potentially speed up your development the most. An ORM handles mapping objects in memory to how they are stored in the database. It can replace a lot of your query writing with simple methods such as user.save(), blogPost.comments(order="date"), and so on. We'll talk a lot more about the ORM in CFWheels in the chapters about models.

There's Your Explanation

So there you have it, a completely fair and unbiased introduction to CFWheels. ;)

If you've been developing ColdFusion applications for a while, then we know this all seems hard to believe. But trust us; it works. And if you're new to ColdFusion or even web development in general, then you probably aren't aware of most of the pains that Wheels was meant to alleviate!

That's okay. You're welcome in the CFWheels camp just the same.

Requirements

What you need to know and have installed before you start programming in CFWheels.

We can identify 3 different types of requirements that you should be aware of:

Project Requirements. Is CFWheels a good fit for your project?
Developer Requirements. Do you have the knowledge and mindset to program effectively in CFWheels?
System Requirements. Is your server ready for CFWheels?

Project Requirements

Before you start learning CFWheels and making sure all the necessary software is installed on your computer, you really need to take a moment and think about the project you intend to use CFWheels on. Is it a ten page website that won't be updated very often? Is it a space flight simulator program for NASA? Is it something in between?

Most websites are, at their cores, simple data manipulation applications. You fetch a row, make some updates to it, stick it back in the database and so on. This is the "target market" for CFWheels--simple CRUD (create, read, update, delete) website applications.

A simple ten page website won't do much data manipulation, so you don't need CFWheels for that (or even ColdFusion in some cases). A flight simulator program will do so much more than simple CRUD work, so in that case, CFWheels is a poor match for you (and so perhaps, is ColdFusion).

If your website falls somewhere in between these two extreme examples, then read on. If not, go look for another programming language and framework. ;)

Another thing worth noting right off the bat (and one that ties in with the simple CRUD reasoning above) is that CFWheels takes a very data-centric approach to the development process. What we mean by that is that it should be possible to visualize and implement the database design early on in the project's life cycle. So, if you're about to embark on a project with an extensive period of object oriented analysis and design which, as a last step almost, looks at how to persist objects, then you should probably also look for another framework.

Still reading?

Good!

Moving on...

Developer Requirements

Yes, there are actually some things you should familiarize yourself with before starting to use CFWheels. Don't worry though. You don't need to be an expert on any on of them. A basic understanding is good enough.

CFML. You should know CFML, the ColdFusion programming language. (Surprise!)
Object Oriented Programming. You should grasp the concept of object oriented programming and how it applies to CFML.
Model-View-Controller. You should know the theory behind the Model-View-Controller development pattern.

CFML

Simply the best web development language in the world! The best way to learn it, in our humble opinion, is to get the free developer edition of Adobe ColdFusion, buy Ben Forta's ColdFusion Web Application Construction Kit series, and start coding using your programming editor of choice. Remember it's not just the commercial Adobe offering that's available; Lucee offers an excellent open source alternative. Using CommandBox is a great and simple way to get a local development environment of your choice up and running quickly.

Object Oriented Programming (OOP)

This is a programming methodology that uses constructs called objects to design applications. Objects model real world entities in your application. OOP is based on several techniques including inheritance, modularity, polymorphism, and encapsulation. Most of these techniques are supported in CFML, making it a fairly functional object oriented language. At the most basic level, a .cfc file in CFML is a class, and you create an instance of a class by using the CreateObject function or the <cfobject> tag.

Trying to squeeze an explanation of object oriented programming and how it's used in CFML into a few sentences is impossible, and a detailed overview of it is outside the scope of this chapter. There is lots of high quality information online, so go ahead and Google it.

Model-View-Controller

Model-View-Controller, or MVC for short, is a way to structure your code so that it is broken down into 3 easy-to-manage pieces:

Model. Just another name for the representation of data, usually a database table.
View. What the user sees and interacts with (a web page in our case).
Controller. The behind-the-scenes guy that's coordinating everything.

MVC is how CFWheels structures your code for you. As you start working with CFWheels applications, you'll see that most of the code you write is very nicely separated into one of these 3 categories.

System Requirements

CFWheels requires that you use one of these CFML engines:

Adobe ColdFusion 10.0.23 / 11.0.12+ / 2016.0.4+ / 2018
Lucee 4.5.5.006 + / 5.2.1.9+

Operating Systems

Your ColdFusion or Lucee engine can be installed on Windows, Mac, UNIX, or Linux—they all work just fine.

Web Servers

You also need a web server. CFWheels runs on all popular web servers, including Apache, Microsoft IIS, Jetty, and the JRun or Tomcat web server that ships with Adobe ColdFusion. Some web servers support URL rewriting out of the box, some support the cgi.PATH_INFO variable which is used to achieve partial rewriting, and some don't have support for either. For local development, we strongly encourage the use of CommandBox.

Don't worry though. CFWheels will adopt to your setup and run just fine, but the URLs that it creates might differ a bit. You can read more about this in the URL Rewriting chapter.

Database Engines

Finally, to build any kind of meaningful website application, you will likely interact with a database. These are the currently supported databases:

SQL Server 7+
MySQL 5+ *
PostgreSQL 8.4+
H2 1.4+

MySQL

CFWheels maybe incompatible with newer MySQL JDBC drivers. It is recommended you downgrade the driver to version 5.1.x for full ORM functionality.
If you're using MySQL 5.7.5+ you should be aware that the ONLY_FULL_GROUP_BY setting is enabled by default and it's currently not compatible with the CFWheels ORM. However, you can work around this by either disabling the ONLY_FULL_GROUP_BY setting or using ANY_VALUE() in a calculated property. You can read more about it here.
We also recommend using the InnoDB engine if you want Transactions to work.
MySQL 4 is not supported.

OK, hopefully this chapter didn't scare you too much. You can move on knowing that you have the basic knowledge needed, the software to run CFWheels, and a suitable project to start with.

Manual Installation

Instructions for installing CFWheels on your system.

Installing CFWheels is so simple that there is barely a need for a chapter devoted to it. But we figured we'd better make one anyway in case anyone is specifically looking for a chapter about installation.

So, here are the simple steps you need to follow to get rolling on CFWheels...

Manual Installation

1. Download CFWheels

You have 2 choices when downloading CFWheels. You can either use the latest official release of CFWheels, or you can take a walk on the wild side and go with the latest committed source code in our Git repository.

The latest official releases can always be found in the Releases section of GitHub, and the Git repository is available at our GitHub repo.

In most cases, we recommend going with the official release because it's well documented and has been through a lot of bug testing. Only if you're in desperate need of a feature that has not been released yet would we advise you to go with the version stored in the Git master branch.

Let's assume you have downloaded the latest official release. (Really, you should go with this option.) You now have a .zip file saved somewhere on your computer. On to the next step...

2. Setup the Website

Getting an empty website running with CFWheels installed is an easy process if you already know your way around IIS or Apache. Basically, you need to create a new website in your web server of choice and unzip the contents of the file into the root of it.

In case you're not sure, here are the instructions for setting up an empty CFWheels site that can be accessed when typing localhost in your browser. The instructions refer to a system running Windows Server 2003 and IIS, but you should be able to follow along and apply the instructions with minor modifications to your system. (See Requirements for a list of tested systems).

Create a new folder under your web root (usually C:\Inetpub\wwwroot) named wheels_site and unzip the CFWheels .zip file into the root of it.
Create a new website using IIS called CFWheels Site with localhost as the host header name and C:\Inetpub\wwwroot\mysite as the path to your home directory.

If you want to run a CFWheels-powered application from a subfolder in an existing website, this is entirely possible, but you may need to get a little creative with your URL rewrite rules if you want to get pretty URLs--it will only work out of the box on recent versions of Apache. (Read more about this in the URL Rewriting chapter.)

3. Setup the Database (Optional)

Create a new database in MySQL, PostgreSQL, Microsoft SQL Server, or H2 and add a new data source for it in the ColdFusion/Lucee Administrator, just as you'd normally do. Now open up config/settings.cfm and call set(dataSourceName="") with the name you chose for the data source.

If you don't want to be bothered by opening up a CFWheels configuration file at all, there is a nice convention you can follow for the naming. Just name your data source with the same name as the folder you are running your website from (mysite in the example above), and CFWheels will use that when you haven't set the dataSourceName setting using the Set() function.

4. Test It

When you've followed the steps above, you can test your installation by typing http://localhost/ (or whatever you set as the host header name) in your web browser. You should get a page saying "Welcome to CFWheels!"

That's it. You're done. This is where the fun begins!

Upgrading

Instructions for upgrading CFWheels applications

CFWheels follows Semantic Versioning (http://semver.org/) so large version changes (e.g, 1.x.x -> 2.x.x) will most likely contain breaking changes which will require evaluation of your codebase. Minor version changes (e.g, 1.3.x->1.4.x) will often contain new functionality, but in a backwards-compatible manner, and maintenance releases (e.g 1.4.4 -> 1.4.5) will just be trying to fix bugs.

Generally speaking, upgrading CFWheels is as easy as replacing the wheels folder, especially for those small maintenance releases: however, there are usually exceptions in minor point releases (i.e, 1.1 to 1.3 required replacing other files outside the wheels folder). The notes below detail those changes.

Upgrading to 2.3.x

Replace the wheels folder with the new one from the 2.3.0 download.

Upgrading to 2.2.x

Replace the wheels folder with the new one from the 2.2.0 download.

Upgrading to 2.1.x

Replace the wheels folder with the new one from the 2.1.0 download.

Code changes

Rename any instances of findLast() to findLastOne()

Changes outside the wheels folder

Create /events/onabort.cfm to support the onAbort method

Upgrading to 2.0.x

As always, the first step is to replace the wheels folder with the new one from the 2.0 download.

Other major changes required to upgrade your application are listed in the following sections.

Supported CFML Engines

CFWheels 2.0 requires one of these CFML engines:

Lucee 4.5.5.006 + / 5.2.1.9+
Adobe ColdFusion 10.0.23 / 11.0.12+ / 2016.0.4+

We've updated our minimum requirements to match officially supported versions from the vendors. (For example, Adobe discontinued support for ColdFusion 10 in May 2017, which causes it to be exposed to security exploits in the future. We've included it in 2.0 but it may be discontinued in a future version)

Changes outside the wheels folder

The events/functions.cfm file has been moved to global/functions.cfm.
The models/Model.cfc file should extend wheels.Model instead of Wheels (models/Wheels.cfc can be deleted).
The controllers/Controller.cfc file should extend wheels.Controller instead of Wheels(controllers/Wheels.cfc can be deleted).
The init function of controllers and models must be renamed to config.
The global setting modelRequireInit has been renamed to modelRequireConfig.
The global setting cacheControllerInitialization has been renamed to cacheControllerConfig.
The global setting cacheModelInitialization has been renamed to cacheModelConfig.
The global setting clearServerCache has been renamed to clearTemplateCache.
The updateProperties() method has been removed, use update() instead.
JavaScript arguments like confirm and disable have been removed from the link and form helper functions (use the JS Confirm and JS Disable plugins to reinstate the old behavior).
The renderPage function has been renamed to renderView
includePartial() now requires the partial and query arguments to be set (if using a query)

Routing

The addRoute() function has been removed in CFWheels 2.0 in favor of a new routing API. See the Routing chapter for information about the new RESTful routing system.

A limited version of the "wildcard" route ([controller]/[action]/[key]) is available as [controller]/[action]) if you use the new wildcard() mapper method:

config/routes.cfm

mapper()
    .wildcard()
.end();

By default, this is limited to GET requests for security reasons.

Cross-Site Request Forgery (CSRF) Protection

It is strongly recommended that you enable CFWheels 2.0's built-in CSRF protection.

For many applications, you need to follow these steps:

In controllers/Controller.cfc, add a call to protectsFromForgery() to the config method.
Add a call to the csrfMetaTags() helper in your layouts' <head> sections.
Configure any AJAX calls that POST data to your application to pass the authenticityToken from the <meta>tags generated by csrfMetaTags() as an X-CSRF-TOKEN HTTP header.
Update your route definitions to enforce HTTP verbs on actions that manipulate data (get, post, patch, delete, etc.)
Make sure that forms within the application are POSTing data to the actions that require post, patch, and delete verbs.

See documentation for the CSRF Protection Plugin for more information.

Note: If you had previously installed the CSRF Protection plugin, you may remove it and rely on the functionality included in the CFWheels 2 core.

Database Migrations

If you have previously been using the dbmigrate plugin, you can now use the inbuilt version within the CFWheels 2 core.

Database Migration files in /db/migrate/ should now be moved to /migrator/migrations and extend wheels.migrator.Migration, not plugins.dbmigrate.Migration which can be changed with a simple find and replace. Note: Oracle is not currently supported for Migrator.

Upgrading to 1.4.x

Replace the wheels folder with the new one from the 1.4 download.
Replace URL rewriting rule files – i.e, .htaccess, web.config, IsapiRewrite.ini

In addition, if you're upgrading from an earlier version of CFWheels, we recommend reviewing the instructions from earlier reference guides below.

Upgrading to 1.3.x

If you are upgrading from CFWheels 1.1.0 or newer, follow these steps:

Replace the wheels folder with the new one from the 1.3 download.
Replace the root root.cfm file with the new one from the 1.3 download.
Remove the <cfheader> calls from the following files:
- events/onerror.cfm
- events/onmaintenance.cfm
- events/onmissingtemplate.cfm

In addition, if you're upgrading from an earlier version of CFWheels, we recommend reviewing the instructions from earlier reference guides below.

Note: To accompany the newest 1.1.x releases, we've highlighted the changes that are affected by each release in this cycle.

Upgrading to 1.1.x

If you are upgrading from Wheels 1.0 or newer, the easiest way to upgrade is to replace the wheels folder with the new one from the 1.1 download. If you are upgrading from an earlier version, we recommend reviewing the steps outlined in Upgrading to Wheels 1.0.

Note: To accompany the newest 1.1.x releases, we've highlighted the changes that are affected by each release in this cycle.

Plugin Compatibility

Be sure to review your plugins and their compatibility with your newly-updated version of Wheels. Some plugins may stop working, throw errors, or cause unexpected behavior in your application.

Supported System Changes

1.1: The minimum Adobe ColdFusion version required is now 8.0.1.
1.1: The minimum Railo version required is now 3.1.2.020.
1.1: The H2 database engine is now supported.

File System Changes

1.1: The .htaccess file has been changed. Be sure to copy over the new one from the new version 1.1 download and copy any addition changes that you may have also made to the original version.

Database Structure Changes

1.1: By default, Wheels 1.1 will wrap database queries in transactions. This requires that your database engine supports transactions. For MySQL in particular, you can convert your MyISAM tables to InnoDB to be compatible with this new functionality. Otherwise, to turn off automatic transactions, place a call to set(transactionMode="none").
1.1: Binary data types are now supported.

CFML Code Changes

Model Code

1.1: Validations will be applied to some model properties automatically. This may cause unintended behavior with your validations. To turn this setting off, call set(automaticValidations=false) in config/settings.cfm.
1.1: The class argument in hasOne(), hasMany(), and belongsTo() has been deprecated. Use the modelName argument instead.
1.1: afterFind() callbacks no longer require special logic to handle the setting of properties in objects and queries. (The "query way" works for both cases now.) Because arguments will always be passed in to the method, you can't rely on StructIsEmpty() to determine if you're dealing with an object or not. In the rare cases that you need to know, you can now call isInstance() or isClass() instead.
1.1: On create, a model will now set the updatedAt auto-timestamp to the same value as the createdAt timestamp. To override this behavior, call set(setUpdatedAtOnCreate=false) in config/settings.cfm.

View Code

1.1: Object form helpers (e.g. textField() and radioButton()) now automatically display a label based on the property name. If you left the label argument blank while using an earlier version of Wheels, some labels may start appearing automatically, leaving you with unintended results. To stop a label from appearing, use label=false instead.
1.1: The contentForLayout() helper to be used in your layout files has been deprecated. Use the includeContent() helper instead.
1.1: In production mode, query strings will automatically be added to the end of all asset URLs (which includes JavaScript includes, stylesheet links, and images). To turn off this setting, call set(assetQueryString=false) in config/settings.cfm.
1.1: stylesheetLinkTag() and javaScriptIncludeTag() now accept external URLs for the source/sources argument. If you manually typed out these tags in previous releases, you can now use these helpers instead.
1.1: flashMessages(), errorMessageOn(), and errorMessagesFor() now create camelCased class attributes instead (for example error-messages is now errorMessages). The same goes for the class attribute on the tag that wraps form elements with errors: it is now fieldWithErrors.

Controller Code

1.1.1: The if argument in all validation functions is now deprecated. Use the condition argument instead.

Upgrading to 1.0.x

Our listing of steps to take while upgrading your Wheels application from earlier versions to 1.0.x.

Upgrading from an earlier version of 1.x? Then the upgrade path is simple. All you need to do is replace the wheels folder with the new wheels folder from the download.

The easiest way to upgrade is to setup an empty website, deploy a fresh copy of Wheels 1.0, and then transfer your application code to it. When transferring, please make note of the following changes and make the appropriate changes to your code.

Note: To accompany the newest 1.0 release, we've highlighted the changes that are affected by that release.

Supported System Changes

1.0: URL rewriting with IIS 7 is now supported.
1.0: URL rewriting in a sub folder on Apache is now supported.
ColdFusion 9 is now supported.
Oracle 10g or later is now supported.
PostgreSQL is now supported.
Railo 3.1 is now supported.

File System Changes

1.0: There is now an app.cfm file in the config folder. Use it to set variables that you'd normally set in Application.cfc (i.e., this.name, this.sessionManagement, this.customTagPaths, etc.)
1.0: There is now a web.config file in the root.
1.0: There is now a Wheels.cfc file in the models folder.
1.0: The Wheels.cfc file in the controllers folder has been updated.
1.0: The IsapiRewrite4.ini and .htaccess files in the root have both been updated.
The controller folder has been changed to controllers.
The model folder has been changed to models.
The view folder has been changed to views.
Rename all of your CFCs in models and controllers to UpperCamelCase. So controller.cfc will become Controller.cfc, adminUser.cfc will become AdminUser.cfc, and so on.
All images must now be stored in the images folder, files in the files folder, JavaScript files in the javascripts folder, and CSS files in the stylesheets folder off of the root.

Database Structure Changes

deletedOn, updatedOn, and createdOn are no longer available as auto-generated fields. Please change the names to deletedAt, updatedAt, and createdAt instead to get similar functionality, and make sure that they are of type datetime, timestamp, or equivalent.

CFML Code Changes

Config Code

1.0: The action of the default route (home) has changed to wheels. The way configuration settings are done has changed quite a bit. To change a Wheels application setting, use the new set() function with the name of the Wheels property to change. (For example, <cfset set(dataSourceName="mydatasource")>.) To see a list of available Wheels settings, refer to the Configuration and Defaults chapter. Model Code
1.0: The extends attribute in models/Model.cfc should now be Wheels.
findById() is now called findByKey(). Additionally, its id argument is now named key instead. For composite keys, this argument will accept a comma-delimited list.
When using a model's findByKey() or findOne() functions, the found property is no longer available. Instead, the functions return false if the record was not found.
A model's errorsOn() function now always returns an array, even if there are no errors on the field. When there are errors for the field, the array elements will contain a struct with name, fieldName, and message elements.
The way callbacks are created has changed. There is now a method for each callback event ( beforeValidation(), beforeValidationOnCreate(), etc.) that should be called from your model's init() method. These methods take a single argument: the method within your model that should be invoked during the callback event. See the chapter on Object Callbacks for an example.

View Code

1.0: The contents of the views/wheels folder have been changed.
The wrapLabel argument in form helpers is now replaced with labelPlacement. Valid values for labelPlacement are before, after, and around.
The first argument for includePartial() has changed from name to partial. If you're referring to it through a named argument, you'll need to replace all instances with partial.
The variable that keeps a counter of the current record when using includePartial() with a query has been renamed from currentRow to current.
There is now an included wheels view folder in views. Be sure to copy that into your existing Wheels application if you're upgrading.
The location of the default layout has changed. It is now stored at /views/layout.cfm. Now controller-specific layouts are stored in their respective view folder as layout.cfm. For example, a custom layout for www.domain.com/about would be stored at /views/about/layout.cfm.
In linkTo(), the id argument is now called key. It now accepts a comma-delimited list in the case of composite keys.
The linkTo() function also accepts an object for the key argument, in which case it will automatically extract the keys from it for use in the hyperlink.
The linkTo() function can be used only for controller-, action-, and route-driven links now. * The url argument has been removed, so now all static links should be coded using a standard "a" tag.

Controller Code

1.0: The extends attribute in controllers/Controller.cfc should now be Wheels. Multiple-word controllers and actions are now word-delimited by hyphens in the URL. For example, if your controller is called SiteAdmin and the action is called editLayout, the URL to access that action would be http://www.domain.com/site-admin/edit-layout.

URL/Routing

The default route for Wheels has changed from [controller]/[action]/[id] to [controller]/[action]/[key]. This is to support composite keys. The params.id value will now only be available as params.key.
You can now pass along composite keys in the URL. Delimit multiple keys with a comma. (If you want to use this feature, then you can't have a comma in the key value itself).

Screencasts

Tutorials, demonstrations, and presentations about the ColdFusion on Wheels framework.

CFWheels 2.x

Create a basic CRUD interface in CFWheels 2.x

Create a basic JSON API in CFWheels 2.x

Routing in CFWheels 2.x - Part 1

Routing in CFWheels 2.x - Part 2

Introduction to Unit Testing in CFWheels 2.x

Unit Testing Controllers in CFWheels 2.x

CFWheels 1.x

Please note that all the webcasts below were created with CFWheels 1.x in mind, and are listed here as they might still be useful to those starting out.

CRUD series

Learn about basic create operations when building standard CRUD functionality in CFWheels

Learn about basic read operations when building standard CRUD functionality in CFWheels

Chris Peters demonstrates updating data in a simple CRUD CFWheels application

Learn how simple it is to delete records in a basic CRUD application using CFWheels

Chris Peters adds data validation to the user registration form

Other

Command Line Tools

CLI Commands

The command line tools extends the functionality of CommandBox with some commands specifically designed for CFWheels development.

CommandBox brings a whole host of command line capabilities to the CFML developer. It allows you to write scripts that can be executed at the command line written entirely in CFML. It allows you to start a CFML server from any directory on your machine and wire up the code in that directory as the web root of the server. What's more is, those servers can be either Lucee servers or Adobe ColdFusion servers. You can even specify what version of each server to launch. Lastly, CommandBox is a package manager for CFML. That means you can take some CFML code and package it up into a module, host it on ForgeBox.io, and make it available to other CFML developers. In fact we make extensive use of these capabilities to distribute CFWheels plugins and templates. More on that later.

Install CommandBox

The first step is to get CommandBox downloaded and running. CommandBox is available for Windows, Mac & Linux, and can be installed manually or using one of the respective package managers for each OS. You can use Chocolatey on Windows, Homebrew on MacOS, or Yum/Apt on Linux depending on your flavor of Linux. Please follow the instructions on how to install CommandBox on your particular operating system. At the end of the installation process you want to make sure the box command is part of your system path so you can call the command from any directory on your system.

So to run the CommandBox version command you could run box version from the shell or you could launch the CommandBox shell and run version inside it.

box version

version

Install the cfwheels-cli CommandBox Module

Okay, now that we have CommandBox installed, let's add the CFWheels CLI module.

install cfwheels-cli

These tools allow you to adopt a more modern workflow and allow you to create and manipulate many CFWheels objects from the command line. By making these tools available in the command line, not only will you be able to speed up your development but you can also utilize these commands in Continuous Integration (CI) and Continuous Deployment (CD) work flows.

wheels - commands
wheels generate - commands
wheels dbmigrate - commands
wheels plugins - commands

wheels - commands

These are the top level commands in the wheels namespace.

`wheels info`

This command is the most basic of the commands and other than printing some pretty ASCII art it also displays the Current Working Directory, the CommandBox Module Root which can be handy when trying to diagnose version discrepancies, and lastly the CFWheels version currently installed. The version is determined from a variaty of sources. First and foremost, if there is a box.json file in the wheels/ directory the version is extracted from that box.json. Alternatively, if there is no box.json file in the wheels/ directory, we look in wheels/events/onapplicationstart.cfm and extract a version number from that file. That is the version number that is displayed on the default congratulations screen by the way. If both of these fail to get us a version number we can use, we ask you to let us know what version of wheels you are using and give you the option of generating a box.json file. This is handy for bringing old legacy installations under CLI control.

`wheels init`

This will attempt to bootstrap an EXISTING wheels app to work with the CLI.

We'll assume the database/datasource exists and the other config options like reloadpassword is all set up. If there's no box.json, create it, and ask for the version number if we can't determine it. If there's no server.json, create it, and ask for cfengine preferences. We'll ignore other templating objects for now, as this will probably be in place too.

`wheels reload`

This command will reload your CFWheels application. In order for this command to work, your local server needs to be started and running. This command basically issues a request to the running CFWheels application to reload as if you were doing it from your browsers address bar. You will be prompted for your reload password that will be passed to the reload endpoint.

`wheels test`

This command will call the Test Runner in a running server and return the results. The command can be run from within the directory of the running server or you can specify the server name to run against. Additionally you can specify the test suite to run, possible choices include the running application's test suite (app), the core framework test suite (core), or a particular plugin's test suite by passing in the plugin name.

`wheels scaffold`

This command will completely scaffold a new object. Typically you would run this command to stub out all the CRUD related files and then follow it up with a series of wheels g property commands to add the individual fields to the object. This command will:

Create a model file
A Default CRUD Controller complete with create/edit/update/delete code
View files for all those actions
Associated test stubs
DB migration file

This command can be run without the server running except the database migration portion because that requires a running database. So if your server is already up and running you can run this command completely including the database migration portion. Afterwards make sure to run wheels reload to reload your application since we just made model changes. If the server isn't running, you can run this command and stub out all the files, then start your server with server start and finally migrate the database with wheels db latest.

`wheels destroy`

This command will destroy a given object. This is highly destructive, given the name, so proceed with caution. If you created an object using the wheels scaffold [objectName] command, this command is the inverse of that command and will remove all elements created by that command.

This command will destroy the following elements:

the models definition file
the controllers definition file
the view sub folder and all it's contents
the model test file
the controller test file
the views test file
resource route configuration

wheels generate - commands

These are the commands in the wheels generate namespace. These commands are called by some of the top level commands but you can use them directly to speed up your development process.

`wheels generate`

The wheels generate command is what CommandBox calls a namespace and contains many sub commands beneath it. It's main purpose is to isolate those sub commands so there is no name collisions. It also has an alias of wheels g which allows you to shorten the commands you have to type. However, we have opted to show all the commands with their full names in the list below.

`wheels generate app-wizard`

Creates a new CFWheels application using our wizard to gather all the necessary information. This is the recommended route to start a new application.

This command will ask for:

An Application Name (a new directory will be created with this name)
Template to use
A reload Password
A datasource name
What local cfengine you want to run
If using Lucee, do you want to setup a local h2 dev database
Do you want to initialize the app as a ForgeBox module

All these three commands are equivalent and will call the same wizard. The wizard in turn gathers all the required data and passes it all off to the wheels generate app command to do all the heavy lifting.

Let's take a look at the wizard pages after issuing the wheels new command:

You can accept the name offered or change it to whatever name you like. We try to clean up the name and take out special characters and spaces if we need to.

You can select a template to use. If you are reading this before CFWheels 2.4 is released you may want to select the Bleeding Edge Base Template.

The datasource is something you'll have to take care of unless you opt to use the H2 Embedded database in a Lucee server. Here you can define the datasource name if you would like to use something different than the application name.

In this step you can choose what CF Engine and version to launch. Lucee has an embedded SQL compliant database server called H2. So if you use one of the Lucee options you can specify to use the H2 database as well. Notice the last item allows you to specify the module slug or URI to a CF Engine not on the list.

On this step you are asked if you'd like to use the H2 Database, in which case we can set everything up for you, or if you would prefer to use another database engine and will take care of setting up the database yourself.

On this last step, you are asked if you want us to include a box.json file so you can eventually submit this to ForgeBox.io for sharing with he world.

This is the confirmation screen that shows all the choices you've made and gives you one last chance to bail out. If you choose to continue, the choices you've made will be sent over to the wheels g app command to do the actual app creation.

If you opted to continue you'll see a bunch of things scroll across your screen as the various items are downloaded and configured. Eventually you will see this status screen letting you know that everything was installed properly.

`wheels generate app`

Create a blank CFWheels app from one of our app templates or a template using a valid Endpoint ID which can come from ForgeBox, HTTP/S, git, github, etc.

By default an app named MyCFWheelsApp will be created in a sub directory called MyCFWheelsApp.

The most basic call...

This can be shortened to...

Here are the basic templates that are available for you that come from ForgeBox

CFWheels Base Template - Stable (default)
CFWheels Base Template - Bleeding Edge
CFWheels Template - HelloWorld
CFWheels Template - HelloDynamic
CFWheels Template - HelloPages
CFWheels Example App
CFWheels - TodoMVC - HTMX - Demo App

The template parameter can also be any valid Endpoint ID, which includes a Git repo or HTTP URL pointing to a package. So you can use this to publish your own templates to use to start new projects.

`wheels generate route`

Adds a default resources Route to the routes table. All the normal CRUD routes are automatically added.

`wheels generate controller`

I generate a controller in the controllers/ directory. You can either pass in a list of actions to stub out or the standard CRUD methods will be generated.

Create a user controller with full CRUD methods

Create a user object with just "index" and "customaction" methods

`wheels generate model`

This command generates a model in the models/ folder and creates the associated DB Table using migrations.

Create "users" table and "User.cfc" in models:

Create just "User.cfc" in models:

`wheels generate property`

This command generates a dbmigration file to add a property to an object and scaffold into _form.cfm and show.cfm if they exist (i.e, wheels generate property table columnName columnType).

Create the a string/textField property called firstname on the User model:

Create a boolean/Checkbox property called isActive on the User model with a default of 0:

Create a boolean/Checkbox property called hasActivated on the User model with a default of 1 (i.e, true):

Create a datetime/datetimepicker property called lastloggedin on the User model:

All columnType options: biginteger,binary,boolean,date,datetime,decimal,float,integer,string,limit,text,time,timestamp,uuid

`wheels generate view`

This command generates a view file in the views/ directory when specifying the object name and the action. If a directory for the object does not exist a subdirectory will be created in the views/ directory and the action NAME.cfm file place into it.

Create a default file called show.cfm without a template

Create a default file called show.cfm using the default CRUD template

`wheels generate test`

This command generates a test stub in /test/TYPE/NAME.cfc.

wheels dbmigrate - commands

These are the commands in the wheels dbmigrate namespace. They allow you to manipulate the database structure and script the changes. This makes is easy to share your changes with coworkers, check them into source control, or apply them automatically when you deploy your code to production.

`wheels dbmigrate`

This is another namespace with sub commands within it. It also has an alias of wheels db which allows you to shorten the command you need to type.

`wheels dbmigrate info`

This command doesn't take any inputs but simply tries to communicate with the running server and gather information about your migrations and displays them in a table.

From the information presented in the two tables you can see how many migration files are in your application and of those how many have already been applied and available to be applied. You are also presented with the datasource name and database type information.

`wheels dbmigrate latest`

This command will migrate the database to the latest version. This command will apply each migration file from the current state all the way to the latest one at a time. If a SQL error is encountered in one of the files, the command will stop at that point and report the error.

`wheels dbmigrate reset`

This command will migrate the database to version 0 effectively resetting the database to nothing.

`wheels dbmigrate up`

This command will process the next migration file from the current state. If the database is already at the latest version this command will have no effect.

`wheels dbmigrate down`

This command will reverse the current migration file and take the database one step backwards. If the database is already at version 0 then this command will have no effect.

`wheels dbmigrate exec`

This command will run a particular migration file and take the database to that version. The four directional migration commands above latest, reset, up, and down each in turn call this command to process their intended action.

`wheels dbmigrate create table`

This command will generate a new migration file for creating a table in the database. Keep in mind you will still have to run the migration file but this will add it to the migration history.

`wheels dbmigrate create column`

This command will generate a new migration file for adding a new column to an existing table.

`wheels dbmigrate create blank`

`wheels dbmigrate remove table`

This command generates a migration file to remove a table. The migration file is will still need to be run individual but this command gets the migration generated and into the history.

wheels plugins - commands

These are the commands in the wheels plugins namespace. Currently this section is pretty sparse, make suggestions of what you may want to see in this section.

`wheels plugins list`

This command will make a call to ForgeBox.io and bring back a list of available CFWheels Plugins listed on ForgeBox.

Working with CFWheels

Conventions

With a convention-over-configuration framework like CFWheels, it's important to know these conventions. This is your guide.

There is a specific set of standards that CFWheels follows when you run it in its default state. This is to save you time. With conventions in place, you can get started coding without worrying about configuring every little detail.

But it is important for you to know these conventions, especially if you're running an operating system and/or DBMS configuration that's picky about things like case sensitivity.

URLs

CFWheels uses a very flexible routing system to match your application's URLs to controllers, views, and parameters.

Within this routing system is a default route that handles many scenarios that you'll run across as a developer. The default route is mapped using the pattern [controller]/[action]/[key].

Consider this example URL:http://localhost/users/edit/12

http://localhost/users/edit/12

This maps to the Users controller, edit action, and a key of 12. For all intents and purposes, this will load a view for editing a user with a primary key value in the database of 12.

This URL pattern works up the chain and will also handle the following example URLs:

URL

Controller

Action

Key

Note that the above conventions are for GET requests and only apply when you have a wildcard() call in config/routes.cfm (which is the default). See for instructions on overriding this behavior and how to deal with PUT, POST etc.

Naming Conventions for Controllers, Actions, and Views

Controllers, actions, and views are closely linked together by default. And how you name them will influence the URLs that CFWheels will generate.

Controllers

First, a controller is a CFC file placed in the controllers folder. It should be named in PascalCase. For example, a site map controller would be stored at controllers/SiteMap.cfc.

Multi-word controllers will be delimited by hyphens in their calling URLs. For example, a URL of /site-map will reference the SiteMap controller.

Actions

Methods within the controllers, known as actions, should be named in camelCase.

Like with controllers, any time a capital letter is used in camelCase, a hyphen will be used as a word delimiter in the corresponding URL. For example, a URL of /site-map/search-engines will reference the searchEngines action in the SiteMap controller.

Views

By default, view files are named after the action names and are stored in folders that correspond to controller names. Both the folder names and view file names should be all lowercase, and there is no word delimiter.

In our /site-map/search-engines URL example, the corresponding view file would be stored at views/sitemap/searchengines.cfm.

Layouts

A special type of view file called a layout defines markup that should surround the views loaded by the application. The default layout is stored at views/layout.cfm and is automatically used by all views in the application.

Controller-level layouts can also be set automatically by creating a file called layout.cfm and storing it in the given controller's view folder. For example, to create a layout for the users controller, the file would be stored at views/users/layout.cfm.

When a controller-level layout is present, it overrides the default layout stored in the root views folder.

Naming Conventions for Models and Databases

By default, the names of CFWheels models, model properties, database tables, and database fields all relate to each other. CFWheels even sets a sensible default for the CFML data source used for database interactions.

Data Sources

CFWheels will automatically look for a data source with the same name as the folder that your application is deployed in. If your CFWheels application is in a folder called blog, CFWheels will look for a data source called blog, for example.

Plural Database Table Names, Singular Model Names

CFWheels adopts a Rails-style naming conventions for database tables and model files. Think of a database table as a collection of model objects; therefore, it is named with a plural name. Think of a model object as a representation of a single record from the database table; therefore, it is named with a singular word.

For example, a user model represents a record from the users database table. CFWheels also recognizes plural patterns like binary/binaries, mouse/mice, child/children, etc.

Like controller files, models are also CFCs and are named in PascalCase. They are stored in the models folder. So the user model would be stored at models/User.cfc.

Everything in the Database Is Lowercase

In your database, both table names and column names should be lowercase. The customersegments table could have fields called title, regionid, and incomelevel, for example.

Because of CFML's case insensitive nature, we recommend that you refer to model names and corresponding properties in camelCase. This makes for easier readability in your application code.

In the customersegments example above, you could refer to the properties in your CFML as title, regionId, and incomeLevel to stick to CFML's Java-style roots. (Built-in CFML functions are often written in camelCase and PascalCase, after all.)

Configuration and Defaults

There are many default values and settings that you can tweak in CFWheels when you need to. Some of them are conventions and others are just configurations available for you to change. You can even change argument defaults for built-in CFWheels functions to keep your code DRYer.

Handling Requests with Controllers

Displaying Views to Users

Database Interaction Through Models

Plugins

External Links

Upgrading

Instructions for upgrading CFWheels applications

Upgrading to 2.3.x

Replace the wheels folder with the new one from the 2.3.0 download.

Upgrading to 2.2.x

Replace the wheels folder with the new one from the 2.2.0 download.

Upgrading to 2.1.x

Replace the wheels folder with the new one from the 2.1.0 download.

Code changes

Rename any instances of findLast() to findLastOne()

Changes outside the wheels folder

Create /events/onabort.cfm to support the onAbort method

Upgrading to 2.0.x

As always, the first step is to replace the wheels folder with the new one from the 2.0 download.

Other major changes required to upgrade your application are listed in the following sections.

Supported CFML Engines

CFWheels 2.0 requires one of these CFML engines:

Lucee 4.5.5.006 + / 5.2.1.9+
Adobe ColdFusion 10.0.23 / 11.0.12+ / 2016.0.4+

Changes outside the wheels folder

The events/functions.cfm file has been moved to global/functions.cfm.
The models/Model.cfc file should extend wheels.Model instead of Wheels (models/Wheels.cfc can be deleted).
The controllers/Controller.cfc file should extend wheels.Controller instead of Wheels(controllers/Wheels.cfc can be deleted).
The init function of controllers and models must be renamed to config.
The global setting modelRequireInit has been renamed to modelRequireConfig.
The global setting cacheControllerInitialization has been renamed to cacheControllerConfig.
The global setting cacheModelInitialization has been renamed to cacheModelConfig.
The global setting clearServerCache has been renamed to clearTemplateCache.
The updateProperties() method has been removed, use update() instead.
JavaScript arguments like confirm and disable have been removed from the link and form helper functions (use the JS Confirm and JS Disable plugins to reinstate the old behavior).
The renderPage function has been renamed to renderView
includePartial() now requires the partial and query arguments to be set (if using a query)

Routing

The addRoute() function has been removed in CFWheels 2.0 in favor of a new routing API. See the Routing chapter for information about the new RESTful routing system.

A limited version of the "wildcard" route ([controller]/[action]/[key]) is available as [controller]/[action]) if you use the new wildcard() mapper method:

config/routes.cfm

mapper()
    .wildcard()
.end();

By default, this is limited to GET requests for security reasons.

Cross-Site Request Forgery (CSRF) Protection

It is strongly recommended that you enable CFWheels 2.0's built-in CSRF protection.

For many applications, you need to follow these steps:

In controllers/Controller.cfc, add a call to protectsFromForgery() to the config method.
Add a call to the csrfMetaTags() helper in your layouts' <head> sections.
Configure any AJAX calls that POST data to your application to pass the authenticityToken from the <meta>tags generated by csrfMetaTags() as an X-CSRF-TOKEN HTTP header.
Update your route definitions to enforce HTTP verbs on actions that manipulate data (get, post, patch, delete, etc.)
Make sure that forms within the application are POSTing data to the actions that require post, patch, and delete verbs.

See documentation for the CSRF Protection Plugin for more information.

Note: If you had previously installed the CSRF Protection plugin, you may remove it and rely on the functionality included in the CFWheels 2 core.

Database Migrations

If you have previously been using the dbmigrate plugin, you can now use the inbuilt version within the CFWheels 2 core.

Upgrading to 1.4.x

Replace the wheels folder with the new one from the 1.4 download.
Replace URL rewriting rule files – i.e, .htaccess, web.config, IsapiRewrite.ini

In addition, if you're upgrading from an earlier version of CFWheels, we recommend reviewing the instructions from earlier reference guides below.

Upgrading to 1.3.x

If you are upgrading from CFWheels 1.1.0 or newer, follow these steps:

Replace the wheels folder with the new one from the 1.3 download.
Replace the root root.cfm file with the new one from the 1.3 download.
Remove the <cfheader> calls from the following files:
- events/onerror.cfm
- events/onmaintenance.cfm
- events/onmissingtemplate.cfm

In addition, if you're upgrading from an earlier version of CFWheels, we recommend reviewing the instructions from earlier reference guides below.

Note: To accompany the newest 1.1.x releases, we've highlighted the changes that are affected by each release in this cycle.

Upgrading to 1.1.x

Note: To accompany the newest 1.1.x releases, we've highlighted the changes that are affected by each release in this cycle.

Plugin Compatibility

Be sure to review your plugins and their compatibility with your newly-updated version of Wheels. Some plugins may stop working, throw errors, or cause unexpected behavior in your application.

Supported System Changes

1.1: The minimum Adobe ColdFusion version required is now 8.0.1.
1.1: The minimum Railo version required is now 3.1.2.020.
1.1: The H2 database engine is now supported.

File System Changes

1.1: The .htaccess file has been changed. Be sure to copy over the new one from the new version 1.1 download and copy any addition changes that you may have also made to the original version.

Database Structure Changes

1.1: By default, Wheels 1.1 will wrap database queries in transactions. This requires that your database engine supports transactions. For MySQL in particular, you can convert your MyISAM tables to InnoDB to be compatible with this new functionality. Otherwise, to turn off automatic transactions, place a call to set(transactionMode="none").
1.1: Binary data types are now supported.

CFML Code Changes

Model Code

1.1: Validations will be applied to some model properties automatically. This may cause unintended behavior with your validations. To turn this setting off, call set(automaticValidations=false) in config/settings.cfm.
1.1: The class argument in hasOne(), hasMany(), and belongsTo() has been deprecated. Use the modelName argument instead.
1.1: afterFind() callbacks no longer require special logic to handle the setting of properties in objects and queries. (The "query way" works for both cases now.) Because arguments will always be passed in to the method, you can't rely on StructIsEmpty() to determine if you're dealing with an object or not. In the rare cases that you need to know, you can now call isInstance() or isClass() instead.
1.1: On create, a model will now set the updatedAt auto-timestamp to the same value as the createdAt timestamp. To override this behavior, call set(setUpdatedAtOnCreate=false) in config/settings.cfm.

View Code

1.1: Object form helpers (e.g. textField() and radioButton()) now automatically display a label based on the property name. If you left the label argument blank while using an earlier version of Wheels, some labels may start appearing automatically, leaving you with unintended results. To stop a label from appearing, use label=false instead.
1.1: The contentForLayout() helper to be used in your layout files has been deprecated. Use the includeContent() helper instead.
1.1: In production mode, query strings will automatically be added to the end of all asset URLs (which includes JavaScript includes, stylesheet links, and images). To turn off this setting, call set(assetQueryString=false) in config/settings.cfm.
1.1: stylesheetLinkTag() and javaScriptIncludeTag() now accept external URLs for the source/sources argument. If you manually typed out these tags in previous releases, you can now use these helpers instead.
1.1: flashMessages(), errorMessageOn(), and errorMessagesFor() now create camelCased class attributes instead (for example error-messages is now errorMessages). The same goes for the class attribute on the tag that wraps form elements with errors: it is now fieldWithErrors.

Controller Code

1.1.1: The if argument in all validation functions is now deprecated. Use the condition argument instead.

Upgrading to 1.0.x

Our listing of steps to take while upgrading your Wheels application from earlier versions to 1.0.x.

Upgrading from an earlier version of 1.x? Then the upgrade path is simple. All you need to do is replace the wheels folder with the new wheels folder from the download.

Note: To accompany the newest 1.0 release, we've highlighted the changes that are affected by that release.

Supported System Changes

1.0: URL rewriting with IIS 7 is now supported.
1.0: URL rewriting in a sub folder on Apache is now supported.
ColdFusion 9 is now supported.
Oracle 10g or later is now supported.
PostgreSQL is now supported.
Railo 3.1 is now supported.

File System Changes

1.0: There is now an app.cfm file in the config folder. Use it to set variables that you'd normally set in Application.cfc (i.e., this.name, this.sessionManagement, this.customTagPaths, etc.)
1.0: There is now a web.config file in the root.
1.0: There is now a Wheels.cfc file in the models folder.
1.0: The Wheels.cfc file in the controllers folder has been updated.
1.0: The IsapiRewrite4.ini and .htaccess files in the root have both been updated.
The controller folder has been changed to controllers.
The model folder has been changed to models.
The view folder has been changed to views.
Rename all of your CFCs in models and controllers to UpperCamelCase. So controller.cfc will become Controller.cfc, adminUser.cfc will become AdminUser.cfc, and so on.
All images must now be stored in the images folder, files in the files folder, JavaScript files in the javascripts folder, and CSS files in the stylesheets folder off of the root.

Database Structure Changes

deletedOn, updatedOn, and createdOn are no longer available as auto-generated fields. Please change the names to deletedAt, updatedAt, and createdAt instead to get similar functionality, and make sure that they are of type datetime, timestamp, or equivalent.

CFML Code Changes

Config Code

1.0: The action of the default route (home) has changed to wheels. The way configuration settings are done has changed quite a bit. To change a Wheels application setting, use the new set() function with the name of the Wheels property to change. (For example, <cfset set(dataSourceName="mydatasource")>.) To see a list of available Wheels settings, refer to the Configuration and Defaults chapter. Model Code
1.0: The extends attribute in models/Model.cfc should now be Wheels.
findById() is now called findByKey(). Additionally, its id argument is now named key instead. For composite keys, this argument will accept a comma-delimited list.
When using a model's findByKey() or findOne() functions, the found property is no longer available. Instead, the functions return false if the record was not found.
A model's errorsOn() function now always returns an array, even if there are no errors on the field. When there are errors for the field, the array elements will contain a struct with name, fieldName, and message elements.
The way callbacks are created has changed. There is now a method for each callback event ( beforeValidation(), beforeValidationOnCreate(), etc.) that should be called from your model's init() method. These methods take a single argument: the method within your model that should be invoked during the callback event. See the chapter on Object Callbacks for an example.

View Code

1.0: The contents of the views/wheels folder have been changed.
The wrapLabel argument in form helpers is now replaced with labelPlacement. Valid values for labelPlacement are before, after, and around.
The first argument for includePartial() has changed from name to partial. If you're referring to it through a named argument, you'll need to replace all instances with partial.
The variable that keeps a counter of the current record when using includePartial() with a query has been renamed from currentRow to current.
There is now an included wheels view folder in views. Be sure to copy that into your existing Wheels application if you're upgrading.
The location of the default layout has changed. It is now stored at /views/layout.cfm. Now controller-specific layouts are stored in their respective view folder as layout.cfm. For example, a custom layout for www.domain.com/about would be stored at /views/about/layout.cfm.
In linkTo(), the id argument is now called key. It now accepts a comma-delimited list in the case of composite keys.
The linkTo() function also accepts an object for the key argument, in which case it will automatically extract the keys from it for use in the hyperlink.
The linkTo() function can be used only for controller-, action-, and route-driven links now. * The url argument has been removed, so now all static links should be coded using a standard "a" tag.

Controller Code

1.0: The extends attribute in controllers/Controller.cfc should now be Wheels. Multiple-word controllers and actions are now word-delimited by hyphens in the URL. For example, if your controller is called SiteAdmin and the action is called editLayout, the URL to access that action would be http://www.domain.com/site-admin/edit-layout.

URL/Routing

The default route for Wheels has changed from [controller]/[action]/[id] to [controller]/[action]/[key]. This is to support composite keys. The params.id value will now only be available as params.key.
You can now pass along composite keys in the URL. Delimit multiple keys with a comma. (If you want to use this feature, then you can't have a comma in the key value itself).

Testing Your Application

With CFWheels, writing automated tests for your application is part of the development lifecycle itself, and running the tests is as simple as clicking a link.

Why Test?

At some point, your code is going to break. Upgrades, feature enhancements, and bug fixes are all part of the development lifecycle. Quite often with deadlines, you don't have the time to test the functionality of your entire application with every change you make.

The problem is that today's fix could be tomorrow's bug. What if there were an automated way of checking if that change you're making is going to break something? That's where writing tests for your application can be invaluable.

In the past, writing test against your application meant downloading, configuring and learning a completely separate framework. This often caused more headaches than it was worth and was the reason why most developers didn't bother writing tests. With CFWheels, we've included a small and very simple testing framework based on RocketUnit to help address just this issue.

The Test Framework

Like everything else in CFWheels, the testing framework is very simple, yet powerful. You don't need to remember a hundred different functions because CFWheels' testing framework contains only a handful.

Conventions

In order to run tests against your application, all tests must reside in the tests directory off the root of your CFWheels application, or within a subdirectory thereof.

When you run the tests for your application, CFWheels recursively scans your application's tests directory for valid tests. Whilst you have freedom to organize your subdirectories, tests and supporting files any way you see fit, we would recommend using the directory structure below as a guide:

tests/
├── functions/
├── requests/

What are these directories for?

The "functions" directory might contain test packages that cover model methods, global or view helper functions.

The "requests" directory might contain test packages that cover controller actions and the output that they generate (views).

Any components that will contain tests must extend the wheels.Test component:

component extends="wheels.Test" {
    // your tests here
}

If the testing framework sees that a component does not extend wheels.Test, that component will be skipped. This lets you create and store any mock components that you might want to use with your tests and keep everything together.

Any test methods must begin their name with "test":

function testExpectedEqualsActual() {
    assert("true");
}

If a method does not begin with test, it is ignored and skipped. This lets you create as many helper methods for your testing components as you want.

Do not var-scope any variables used in your tests. In order for the testing framework to access the variables within the tests that you're writing, all variables need to be within the component's variables scope. The easy way to do this is to just not var variables within your tests, and your CFML engine will automatically assign these variables into the variables scope of the component for you. You'll see this in the examples below.

Setup & Teardown

When writing a group of tests, it's common for there to be some duplicate code, global configuration, and/or cleanup needs that need to be run before or after each test. In order to keep things DRY (Don't Repeat Yourself), the testing framework offers 2 special methods that you can optionally use to handle such configuration.

setup(): Used to initialize or override any variables or execute any code that needs to be run before each test.

teardown(): Used to clean up any variables or execute any code that needs to be ran after each test.

Example:

function setup() {
  _controller = controller(name="dummy");

  args = {
    fromTime=Now(),
    includeSeconds=true;
  };
}

function testWithSecondsBelow5Seconds() {
  number = 5 - 1;
  args.toTime = DateAdd("s", number, args.fromTime);
  actual = _controller.distanceOfTimeInWords(argumentCollection=args);
  expected = "less than 5 seconds";

  assert("actual eq expected");
}

function testWithSecondsBelow10Seconds() {
  number = 10 - 1;
  args.toTime = DateAdd("s", number, args.fromTime);
    actual = _controller.distanceOfTimeInWords(argumentCollection=args);
  expected = "less than 10 seconds";

  assert("actual eq expected");
}

Evaluation

assert(): This is the main method that you will be using when developing tests. To use, all you have to do is provide a quoted expression. The power of this is that ANY 'truthy' expression can be used.

An example test that checks that two values equal each other:

function testActualEqualsExpected() {
  actual = true;
  expected = true;
  assert("actual eq expected");
}

An example test that checks that the first value is less then the second value:

function testOneIsLessThanFive() {
  one = 1;
  five = 5;
  assert("one lt five");
}

You get the idea since you've used these kinds of expressions a thousand times. If you think of the assert()command as another way of using evaluate(), it will all make sense. Remember that you can use any expression that evaluates to a boolean value, so if you can write assertions against structures, arrays, objects, you name it, you can test it!

An example test that checks that a key exists in a structure:

function testKeyExistsInStructure() {
  struct = {
    foo="bar"
  };
  key = "foo";
  assert("StructKeyExists(struct, key)");
}

raised(): Used when you want to test that an exception will be thrown. raised() will raise and catch the exception and return to you the exception type (think cfcatch.type). Just like assert(), raised() takes a quoted expression as its argument.

An example of raising the Wheels.TableNotFound error when you specify an invalid model name:

function testTableNotFound() {
  actual = raised("model('thisHasNoTable')");
  expected = "Wheels.TableNotFound";
  assert("actual eq expected");
}

Debugging

debug(): Will display its output after the test result so you can examine an expression more closely.

expression (string) - a quoted expression to display display (boolean) - whether or not to display the output

TIP

Overloaded arguments will be passed to the internal cfdump attributeCollection

function testKeyExistsInStructure() {
  struct = {
    foo="bar"
  };
  key = "foo";

  // displaying the debug output
  debug("struct");

  // calling debug but NOT displaying the output
  debug("struct", false);

  // displaying the output of debug as text with a label
  debug(expression="struct", format="text", label="my struct");

  assert("StructKeyExists(struct, key)");
}

Testing Your Models

The first part of your application that you are going to want to test against are your models because this is where all the business logic of your application lives. Suppose that we have the following model:

component extends="Model" {
  public void function config() {
    // validation
    validate("checkUsernameDoesNotStartWithNumber")
    // callbacks
    beforeSave("sanitizeEmail");
  }

  /**
   * Check the username does not start with a number
   */
  private void function checkUsernameDoesNotStartWithNumber() {
    if (IsNumeric(Left(this.username, 1))) {
        addError(
        property="username",
        message="Username cannot start with a number."
      );
    }
  }

  /**
   * trim and force email address to lowercase before saving
   */
  private void function sanitizeEmail() {
      this.email = Trim(LCase(this.email));
  }
}

As you can see from the code above, our model has a beforeSave callback that runs whenever we save a user object. Let's get started writing some tests against this model to make sure that our callback works properly.

First, create a test component called /tests/models/TestUserModel.cfc, and in the setup function, create an instance of the model that we can use in each test that we write. We will also create a structure containing some default properties for the model.

function setup() {
  // create an instance of our model
  user = model("user").new();

  // a structure containing some default properties for the model
  properties = {
      firstName="Hugh",
      lastName="Dunnit",
      email="hugh@example.com",
      username="myusername",
      password="foobar",
      passwordConfirmation="foobar"
  };
}

As you can see, we invoke our model by using the model() method just like you would normally do in your controllers.

The first thing we do is add a simple test to make sure that our custom model validation works.

function testUserModelShouldFailCustomValidation() {
  // set the properties of the model
  user.setProperties(properties);
  user.username = "2theBatmobile!";

  // run the validation
  user.valid();

  actual = user.allErrors()[1].message;
  expected = "Username cannot start with a number.";

  // assert that the expected error message is generated
  assert("actual eq expected");
}

Now that we have tests to make sure that our model validations work, it's time to make sure that the callback works as expected when a valid model is created.

function testSanitizeEmailCallbackShouldReturnExpectedValue() {
  // set the properties of the model
  user.setProperties(properties);
  user.email = " FOO@bar.COM ";

  /*
    Save the model, but use transactions so we don't actually write to
    the database. this prevents us from having to have to reload a new
    copy of the database every time the test runs.
  */
  user.save(transaction="rollback");

  // make sure that email address was sanitized
  assert('user.email eq "foo@bar.com"');
}

Testing Your Controllers

The next part of our application that we need to test is our controller. Below is what a typical controller for our user model would contain for creating and displaying a list of users:

component extends="Controller" {

  // users/index
  public void function index() {
    users = model("user").findAll();
  }

  // users/new
  public void function new() {
    user = model("user").new();
  }

  // users/create
  public any function create() {
    user = model("user").new(params.user);

    // Verify that the user creates successfully
    if (user.save()) {
      flashInsert(success="The user was created successfully.");
      // notice something about this redirectTo?
      return redirectTo(action="index");
    }
    else {
      flashInsert(error="There was a problem creating the user.");
      renderView(action="new");
    }
  }
}

Notice the return in the create action in the redirectTo() method? The reason for this is quite simple, under the covers, when you call redirectTo(), CFWheels is using cflocation. As we all know, there is no way to intercept or stop a cflocation from happening. This can cause quite a number of problems when testing out a controller because you would never be able to get back any information about the redirection.

To work around this, the CFWheels test framework will "delay" the execution of a redirect until after the controller has finished processing. This allows CFWheels to gather and present some information to you about what redirection will occur.

The drawback to this technique is that the controller will continue processing and as such we need to explicitly exit out of the controller action on our own, thus the reason why we use return.

Let's create a test package called /tests/controllers/TestUsersController.cfc to test that the create action works as expected:

function testRedirectAndFlashStatus() {
  // define the controller, action and user params we are testing
  local.params = {
    controller="users",
    action="create",
    user={
      firstName="Hugh",
      lastName="Dunnit",
      email="hugh@somedomain.com",
      username="myusername",
      password="foobar",
      passwordConfirmation="foobar"
    }
    };

  // process the create action of the controller
  result = processRequest(params=local.params, method="post", returnAs="struct");

  // make sure that the expected redirect happened
  assert("result.status eq 302");
  assert("result.flash.success eq 'Hugh was created'");
  assert("result.redirect eq '/users/show/1'");

}

Notice that a lot more goes into testing a controller than a model. The first step is setting up the params that will need to be passed to the controller. We then pass the 'params' to the processRequest() function which returns a structure containing a bunch of useful information.

We use this information to make sure that the controller redirected the visitor to the index action once the action was completed.

Note: processRequest() is only for use within the test framework.

Below are some examples of how a controller can be tested:

// asserts that a failed user update returns a 302 http response, an error exists in the flash and will be redirected to the error page
function testStatusFlashAndRedirect() {
  local.params = {
    controller = "users",
    action = "update"
  };
  result = processRequest(params=local.params, method="post", rollback=true, returnAs="struct");
  assert("result.status eq 302");
  assert("StructKeyExists(result.flash, 'error') eq true");
  assert("result.redirect eq '/common/error'");
}

// asserts that expected results are returned. Notice the update transactions is rolled back
function testStatusDatabaseUpdateEmailAndFlash() {
  local.params = {
    controller = "users",
    action = "update",
    key = 1,
    user = {
      name = "Hugh"
    }
  }
  transaction {

    result = processRequest(params=local.params, method="post", returnAs="struct");

    user = model("user").findByKey(1);
    transaction action="rollback";
  }
  assert("result.status eq 302");
  assert("user.name eq 'Hugh'");
  assert("result.emails[1].subject eq 'User was updated'");
  assert("result.flash.success eq 'User was updated'");
}

// asserts that an api request returns the expected JSON response
function testJsonApi() {
  local.params = {
    controller = "countries",
    action = "index",
    format = "json",
    route = "countries"
  };
  result = DeserializeJSON(processRequest(local.params)).data;
  assert("ArrayLen(result) eq 196");
}

// asserts that an API create method returns the expected result
function testJsonApiCreate() {
  local.params = {
    action = "create",
    controller = "users",
    data = {
      type = "users",
      attributes = {
        "first-name" = "Hugh",
        "last-name" = "Dunnit"
      }
    },
    format = "json",
    route = "users"
  };
  result = processRequest(params=local.params, returnAs="struct").status;
  assert("result.status eq 201");
}

Testing Controller Variables

If you want to test a variable that's being set on a controller you can make use of the this scope. This way it's available from outside the controller, which makes it testable.

this.employeeNumber = params.empNum;

// Then from your test...

local.controller = controller(...);
local.controller.processAction();
theValue = local.controller.employeeNumber;

If you think that's too "ugly", you can instead make a public function on the controller that returns the value and then call that from your tests.

Testing Partials

You may at some point want to test a partial (usually called via includePartial()) outside of a request. You'll notice that if you just try and call includePartial() from within the test suite, it won't work. Thankfully there's a fairly easy technique you can use by calling a "fake" or "dummy" controller.

component extends="tests.Test" {
    function setup() {
          params = {controller="dummy", action="dummy"};
          _controller = controller("dummy", params);
    }

    function testMyPartial(){
        result = _controller.includePartial(partial="/foo/bar/");
        assert("result CONTAINS 'foobar'");
    }
}

Testing Your Views

Next we will look at testing the view layer. Below is the code for new.cfm, which is the view file for the controller's new action:

<cfoutput>

<h1>Create a New user</h1>

#flashMessages()#

#errorMessagesFor("user")#

#startFormTag(route="users")#
    #textField(objectName='user', property='username')#
    #passwordField(objectName='user', property='password')#
    #passwordField(objectName='user', property='passwordConfirmation')#
    #textField(objectName='user', property='firstName')#
    #textField(objectName='user', property='lastName')#
    <p>
      #submitTag()# or
      #linkTo(text="Return to the listing", route="users")#
    </p>
#endFormTag()#

</cfoutput>

Testing the view layer is very similar to testing controllers, we will setup a params structure to pass to the processRequest() function which will return (among other things) the generated view output.

Once we have this output, we can then search through it to make sure that whatever we wanted the view to display is presented to our visitor. In the test below, we are simply checking for the heading.

function testUsersIndexContainsHeading() {

  local.params = {
    controller = "users",
    action = "index"
  };

  result = processRequest(params=local.params, returnAs="struct");

  assert("result.status eq 200");
  assert("result.body contains '<h1>Create a New user</h1>'");
}

Testing Your Application Helpers

Next up is testing global helper functions. Below is a simple function that removes spaces from a string.

// global/functions.cfm

public string function stripSpaces(required string string) {
    return Replace(arguments.string, " ", "", "all");
}

Testing these helpers is fairly straightforward. All we need to do is compare the function's return value against a value that we expect, using the assert() function.

function testStripSpacesShouldReturnExpectedResult() {
    actual = stripSpaces(" foo   -   bar     ");
  expected = "foo-bar";
    assert("actual eq expected");
}

Testing Your View Helpers

Testing your view helpers are very similar to testing application helpers except we need to explicitly include the helpers in the setup() function so our view functions are available to the test framework.

Below is a simple function that returns a string wrapped in h1 tags.

// views/helpers.cfm

public string function heading(required string text, string class="foo") {
    return '<h1 class="#arguments.class#">#arguments.text#</h1>';
}

And in our view test package:

function setup() {
  // include our helper functions
  include "/views/helpers.cfm";
  text = "Why so serious?";
}

function testHeadingReturnsExpectedMarkup() {
  actual = heading(text=text);
  expected = '<h1 class="foo">#text#</h1>'
  assert("actual eq expected")
}

function testHeadingWithClassReturnsExpectedMarkup() {
  actual = heading(text=text, class="bar");
  expected = '<h1 class="bar">#text#</h1>'
  assert("actual eq expected")
}

Testing Plugins

Testing plugins requires slightly different approaches depending on the mixin attribute defined in the plugin's main component.

Below is a simple plugin called timeAgo that extends CFWheels' timeAgoInWords view helper by appending "ago" to the function's return value. Take note of the mixin="controller" argument as this will play a part in how we test the plugin.

component mixin="controller" {

    public any function init() {
        this.version = "2.0";
        return this;
    }

    /*
     * Append the term "ago" to the timeAgoInWords core function
     */
    public string function timeAgo() {
        return core.timeAgoInWords(argumentCollection=arguments) & " " & __timeAgoValueToAppend();
    }

    /*
     * Define the term to append to the main function
     */
    private string function __timeAgoValueToAppend() {
        return "ago";
    }
}

In order to test our plugin, we'll need to do a little setup. Our plugin's tests will reside in a directory within our plugin package named tests. We'll also need a directory to keep test assets, in this case a dummy controller that we will need to instantiate in out test's setup() function.

plugins/
├─ timeago/
    └─ TimeAgo.cfc
    └─ index.cfm
    └─ tests/
        └─ TestTimeAgo.cfc
        └─ assets/
            └─ controllers/
                └─ Dummy.cfc

The /plugins/timeago/tests/assets/controllers/Dummy.cfc controller contains the bare minimum for a controller.

component extends="wheels.Controller" {
}

Firstly, in our /plugins/timeago/tests/TestTimeAgo.cfc we'll need to copy the application scope so that we can change some of CFWheels' internal paths. Fear not, we'll reinstate any changes after the tests have finished executing using the teardown function. so that if you're running your tests on your local development machine, your application will continue to function as expected after you're done testing.

Once the setup is done, we simply execute the plugin functions and assert that the return values are what we expect.

component extends="wheels.Test" {

    function setup() {
        // save the original environment
        applicationScope = Duplicate(application);
        // a relative path to our plugin's assets folder where we will store any plugin specific components and files
        assetsPath = "plugins/timeAgo/tests/assets/";
        // override wheels' path with our plugin's assets directory
        application.wheels.controllerPath = assetsPath & "controllers";
        // clear any plugin default values that may have been set
        StructDelete(application.wheels.functions, "timeAgo";
        // we're always going to need a controller for these tests so we'll just create a dummy
        _params = {controller="foo", action="bar"};
        dummyController = controller("Dummy", _params);
    }

    function teardown() {
        // reinstate the original application environment
        application = applicationScope;
    }

    // testing main public function
    function testTimeAgoReturnsExpectedValue() {
        actual = dummyController.timeAgo(fromTime=Now(), toTime=DateAdd("h", -1, Now()));
        expected = "About 1 hour ago";
        assert("actual eq expected");
    }

    // testing the 'private' function
    function testTimeAgoValueToAppendReturnsExpectedValue() {
        actual = dummyController.__timeAgoValueToAppend();
        expected = "ago";
        assert("actual eq expected");
    }
}

If your plugin is uses mixin="model", you will need to create and instantiate a dummy model component.

Running Your Tests

Down in the debug area of your CFWheels application (that grey area at the bottom of the page), you will notice a some links for running tests for the following areas:

Run Tests Runs all tests that you have created for your application. You should run these tests before deploying your application.

View Tests Shows a list of all your test packages with links to run individual packages or single tests.

Framework Tests If you have cloned the CFWheels repository, you will also see a link to run the core framework unit tests.

Plugin Tests If a plugin has a /tests directory, you will also see a link to run the plugin's tests.

The test URL will look something like this: /index.cfm?controller=wheels&action=wheels&view=tests&type=app

Running an individual package: /index.cfm?controller=wheels&action=wheels&view=tests&type=app&package=controllers

Running a single test: /index.cfm?controller=wheels&action=wheels&view=tests&type=app&package=controllers&test=testCaseOne

These URLs are useful should you want an external system to run your tests.

Test Resuts Format

CFWheels can return your test results in either HTML, JUnit or JSON formats, simply by using the format url parameter. Eg: format=junit

Additional Techniques

Once you're comfortable with the concepts thus far, there are a few more functions available which can be used to modify the behavior of your test suite.

beforeAll() - Runs once before the test suite has run. Here is where you might populate a test database or set suite-specific application variables*.

afterAll() - Runs once after the test suite has finished.

packageSetup() - Used in a test package, similar to setup() but only runs once before a package's first test case. Here is where you might set variables that are common to all the tests in a CFC.

packageTeardown() - Used in a test package, similar to teardown() but only runs once after a package's last test case. Here is where you might cleanup files, database rows created by test cases or revert application variables in a CFC.

A typical test request lifecycle will look something like this:

Test.cfc -beforeAll()

Foo.cfc - packageSetup() Foo.cfc - setup() Foo.cfc - testCaseOne() Foo.cfc - teardown() Foo.cfc - setup() Foo.cfc - testCaseTwo() Foo.cfc - teardown() Foo.cfc - packageTeardown()

Bar.cfc - packageSetup() Bar.cfc - setup() Bar.cfc - testCaseThree() Bar.cfc - teardown() Bar.cfc - packageTeardown()

Test.cfc - afterAll()

In order to use beforeAll() and afterAll(), you'll need to make a few small changes to your test suite. Firstly, create a Test.cfc in the root of your /tests/ directory. This is where you'll define your beforeAll() and afterAll() functions and it should look something like this:

component extends="wheels.Test" output=false {

  /*
   * Executes once before the test suite runs.
   */
  function beforeAll() {

  }

  /*
   * Executes once after the test suite runs.
   */
  function afterAll() {

  }

  /*
   * Executes before every tests case unless overridden in a package.
   */
  function setup() {

  }

  /*
   * Executes after every tests case unless overridden in a package.
   */
  function teardown() {

  }

}

For your test packages to inherit these functions, you'll need to change the extends attribute in your test packages to extends="tests.Test". This enables the CFWheels test framework to run your functions.

Since we've implemented the new Test.cfc component, we now have global setup() and teardown() functions will run respectively before and after every test case. If we want to prevent these from running in a particular package, we simply override the global functions like this:

function setup() {
  // your setup code
}

function teardown() {
  // your teardown code
}

If we want to run the global function AND some package-specific setup & teardown code, here's how achieve that:

function setup() {
  super.setup();
  // your setup code
}

function teardown() {
  super.teardown();
  // your teardown code
}

Whilst best practice recommends that tests should be kept as simple and readable as possible, sometimes moving commonly used code into test suite helpers can greatly improve the simplicity of your tests.

Some examples may include, serializing complex values for use in assert() or grouping multiple assertions together. Whatever your requirements, there are a number of ways to use test helpers.

Put your helper functions in your /tests/Test.cfc. These will be available to any package that extends this component. Be mindful of functions you put in here, as it's easy to create naming collisions.
If you've arranged your tests into subdirectories, you can create a helpers.cfm file in any given directory and simply include it in the package.
Put package-specific helper functions in the same package as the tests that use it. These will only be available to the tests in that package. To ensure that these test helpers are not run as tests, use a function name that doesn't start with "test_". Eg: $simplify()

component extends="tests.Test" {

  // 1. All functions in /tests/Test.cfc will be available

  // 2. Include a file containing helpers
  include "helpers.cfm";

  // 3. This is only available to this package
  function $simplify(required string string) {
    local.rv = Replace(arguments.string, " ", "", "all");
    local.rv = Replace(local.rv, Chr(13), "", "all");
    local.rv = Replace(local.rv, Chr(10), "", "all");
    return local.rv;
  }

}

Overloading application vars.. CFWheels will revert the application scope after all tests have completed.

Caveat: The test suite request must complete without uncaught exceptions. If an uncaught exception occurs, the application scope may stay 'dirty', so it's recommended to reload the application by adding reload=true param to your url whilst developing your test packages.

Learn By Example: CFWheels Core

The CFWheels core uses this test framework for its unit test suite and contains a wealth of useful examples. They can all be found in the tests folder of the CFWheels git repo.

Routing

The routing system in CFWheels encourages a conventional RESTful and resourceful style of request handling.

The CFWheels routing system inspects a request's HTTP verb and URL and decides which controller and action to run.

Consider the following request:

The routing system may match the request to a route like this, which tells CFWheels to load the show action on the Products controller:

Configuring Routes

To configure routes, open the file at config/routes.cfm.

The CFWheels router begins with a call to , various methods chained from that, and lastly ends with a call to end().

In many cases, if you need to know where to go in the code to work with existing functionality in an application, the routes.cfm file can be a handy map, telling you which controller and action to start looking in.

How Routes Work

The various route mapping methods that we'll introduce in this chapter basically set up a list of routes, matching URL paths to a controllers and actions within your application.

The terminology goes like this:

Name

A route name is set up for reference in your CFML code for building , , and such. To build URLs, you'll use this name along with helpers like , , , and so on.

Method

A HTTP request method must be defined: GET, POST, PATCH, or DELETE.

You typically want to require POST, PATCH, or DELETE when a given action changes the state of your application's data:

Creating record(s): POST
Updating record(s): PATCH
Deleting record(s): DELETE

You can permit listing and showing records behind a normal HTTP GET request method.

Pattern and Parameters

A pattern is a URL path, sometimes with parameters in [squareBrackets]. Parameter values get sent to the controller in the params struct.

You'll see patterns like these in routes:

In this example, key and slug are parameters that must be present in the URL for the first route to match, and they are required when linking to the route. In the controller, these parameters will be available at params.key and params.slug, respectively.

When a request is made to CFWheels, the router will look for the first route that matches the requested URL. As an example, this means that if key is present in the URL but not slug, then it's the second route above that will match.

Viewing a List of Routes

In the debugging footer, you'll see a View Routes link next to your application's name:

[Reload, View Routes, Run Tests, View Tests]

Clicking that will load a filterable list of routes drawn in the config/routes.cfm file, including name, method, pattern, controller, and action.

Resource Routing

Many parts of your application will likely be CRUD-based (create, read, update, delete) for specific types of records (users, products, categories). Resources allow you to define a conventional routing structure for this common use case.

Resources are important

You'll want to pay close attention to how resource-based routing works because this is considered an important convention in CFWheels applications.

This will set up the following routes, pointing to specific actions within the products controller:

Because the router uses a combination of HTTP verb and path, we only need 4 different URL paths to connect to 7 different actions on the controller.

Whats with the PUT?

There has been some confusion in the web community on whether requests to update data should happen along with a PUT or PATCH HTTP verb. It has been settled mostly that PATCH is the way to go for most situations. CFWheels resources set up both PUT and PATCH to address this confusion, but you should probably prefer linking up PATCH when you are able.

Singular Resources

CFWheels also provides a singular resource for routing that will not expose a primary key through the URL.

This is handy especially when you're manipulating records related directly to the user's session (e.g., a profile or a cart can be managed by the user without exposing the primary key of the underlying database records).

Note that even though the resource path is singular, the name of the controller is plural by convention.

Also, this example is slightly contrived because it doesn't make much sense to create a "new" cart as a user typically just has one and only one cart tied to their session.

Defining Individual URL Endpoints

As you've seen, defining a resource creates several routes for you automatically, and it is great for setting up groupings of routes for managing resources within your application.

As a refresher, these are the intended purpose for each HTTP verb:

Security Warning

We strongly recommend that you not allow any GET requests to modify resources in your database (i.e., creating, updating, or deleting records). Always require POST, PUT, PATCH, or DELETE verbs for those sorts of routing endpoints.

Consider a few examples:

Rather than creating a whole resource for simple one-off actions or pages, you can create individual endpoints for them.

Notice that you can use the to="controller##action" or use separate controller/action arguments. The toargument allows you to delineate controller and action within a single string using a # separator (which must be escaped as a double ## because of CFML's special usage of that symbol within string syntax).

In fact, you could mock a users resource using these methods like so (though obviously there is little practical reason for doing so):

Browser Support for PUT, PATCH, and DELETE

While web standards advocate for usage of these specific HTTP verbs for requests, web browsers don't do a particularly good job of supporting verbs other than GET or POST.

To get around this, the CFWheels router recognizes the specialized verbs from browsers (PUT, PATCH, and DELETE) in this way:

Via a POST request with a
POST variable named _method specifying the specific HTTP verb (e.g., _method=delete)

Note that using CFWheels to write a REST API doesn't typically have this constraint. You should confidently require API clients to use the specific verbs like PATCH and DELETE.

Namespaces

The CFWheels router allows for namespaces: the ability to add a route to a "subfolder" in the URL as well as within the controllers folder of your application.

Let's say that we want to have an "admin" section of the application that is separate from other "public" sections. We'd want for all of the "admin" controllers to be within an admin subfolder both in the URL and our application.

In this example, we have an admin section that will allow the user to manage products. The URL would expose the products section at /admin/products, and the controller would be stored at controllers/admin/Products.cfc.

Packages

Let's say that you want to group a set of controllers together in a subfolder (aka package) in your application but don't want to affect a URL. You can do so using the package mapper method:

With this setup, end users will see /articles and /profile in the URL, but the controllers will be located at controllers/public/Articles.cfc and controllers/public/Profiles.cfc, respectively.

Nested Resources

You'll often find yourself implementing a UI where you need to manipulate data scoped to a parent record. Creating nested resources allows you to reflect this nesting relationship in the URL.

Let's consider an example where we want to enable CRUD for a customer and its children appointment records.

In this situation, we'd perhaps want for our URL to look like this for editing a specific customer's appointment:

To code up this nested resource, we'd write this code in config/routes.cfm:

That will create the following routes:

Notice that the routes for the appointments resource contain a parameter named customerKey. The parent resource's ID will always be represented by its name appended with Key. The child will retain the standard key ID.

You can nest resources and routes as deep as you want, though we recommend considering making the nesting shallower after you get to a few levels deep.

Here's an example of how nesting can be used with different route mapping methods:

Wildcard Routes

CFWheels 1.x had a default routing pattern: [controller]/[action]/[key]. The convention for URLs was as follows:

With this convention, the URL above told CFWheels to invoke the show action in the news controller. It also passed a parameter called key to the action, with a value of 5.

CFWheels 2 will only generate routes for [controller]/[action], however, because resources and the other routing methods are more appropriate for working with records identified by primary keys.

Here is a sample of the patterns that wildcard generates:

The wildcard method by default will only generate routes for the GET request method. If you would like to enable other request methods on the wildcard, you can pass in the method or methods argument:

Security Warning

Specifying a method argument to wildcard with anything other than get gives you the potential to accidentally expose a route that could change data in your application with a GET request. This opens your application to Cross Site Request Forgery (CSRF) vulnerabilities.

wildcard is provided for convenience. Once you're comfortable with routing concepts in CFWheels, we strongly recommend that you use resources (resources, resource) and the other verb-based helpers (get, post, patch, put, and delete) listed above instead.

Order of Precedence

CFWheels gives precedence to the first listed custom route in your config/routes.cfm file.

Consider this example to demonstrate when this can create unexpected issues:

In this case, when the user visits /users/promoted, this will load the show action of the users controller because that was the first pattern that was matched by the CFWheels router.

To fix this, you need the more specific route listed first, leaving the dynamic routing to pick up the less specific pattern:

Making a Catch-All Route

Sometimes you need a catch-all route in CFWheels to support highly dynamic websites (like a content management system, for example), where all requests that are not matched by an existing route get passed to a controller/action that can deal with it.

Let's say you want to have both /welcome-to-the-site and /terms-of-use handled by the same controller and action. Here's what you can do to achieve this.

First, add a new route to config/routes.cfm that catches all pages like this:

Now when you access /welcome-to-the-site, this route will be triggered and the show action will be called on the pages controller with params.title set to welcome-to-the-site.

The problem with this is that this will break any of your normal controllers though, so you'll need to add them specifically before this route. (Remember the order of precedence explained above.)

You'll end up with a config/routes.cfm file looking something like this:

Constraints

The constraints feature can be added either at an argument level directly into a resources() or other individual route call, or can be added as a chained function in it's own right. Constraints allow you to add regex to a route matching pattern, so you could for instance, have /users/1/ and /users/bob/ go to different controller actions.

Constraints can also be used as a wrapping function:

In this example, the key argument being made of digits only will apply to all the nested resources

Wildcard Segments

Wildcard segments allow for wildcards to be used at any point in the URL pattern.

In the above example, anything/you/want you gets set to the params.username including the /'s. The second example would require /search/ to be on the end of the URL

Shallow Resources

If you have a nested resource where you want to enforce the presence of the parent resource, but only on creation of that resource, then shallow routes can give you a bit of a short cut. An example might be Blog Articles, which have Comments. If we're thinking in terms of our models, let's say that Articles Have Many Comments.

Without shallow routes, this block would create RESTful actions for all the nested resources, for example /articles/[articleKey]/comments/[key]

With Shallow resources, we can automatically put the index, create and new RESTful actions with the ArticleKey in the URL, but then separate out edit, show, update and delete actions into their own, and simpler URL path; When we edit or update a comment, we're doing it on that object as it's own entity, and the relationship to the parent article already exists.

So in this case, we get index, new and create with the /articles/[articleKey]/ part in the URL, but to show, edit, update or delete a comment, we can just fall back to /comments/

Member and Collection Blocks

A member() block is used within a nested resource to create routes which act 'on an object'; A member route will require an ID, because it acts on a member. photos/1/preview is an example of a member route, because it acts on (and displays) a single object.

A collection route doesn't require an id because it acts on a collection of objects. photos/search is an example of a collection route, because it acts on (and displays) a collection of objects.

Redirection

As of CFWheels 2.1, you can now use a redirect argument on GET, POST, PUT, PATCH, and DELETE requests. This will execute before reaching any controllers, and perform a 302 redirect immediately after the route is matched.

CFScript

This is useful for the occasional redirect, and saves you having to create a dedicated controller filter or action just to perform a simple task. For large amounts of redirects, you may want to look into adding them at a higher level - e.g in an Apache VirtualHost configuration, as that will be more performant.

Disabling automatic [format] routes

Note

Introduced in CFWheels 2.1

By default, CFWheels will add .[format] routes when using resources(). You may wish to disable this behavior to trim down the number of generated routes for clarity and performance reasons (or you just don't use this feature!).

You can either disable this via mapFormat = false on a per resource basis, or more widely, on a mapper basis:

Configuration and Defaults

An overview of CFWheels configuration and how is it used in your applications. Learn how to override a CFWheels convention to make it your own.

We all love the "Convention over Configuration" motto of CFWheels, but what about those two cases that pop into everyone's head? What if I want to develop in my own way? Or, What about an existing application that I need to port into CFWheels? Gladly, that's what configuration and defaults are there for. Let's take a look at exactly how this is performed.

Where Configurations Happen

You will find configuration files in the config folder of your CFWheels application. In general, most of your settings will go in config/settings.cfm.

You can also set values based on what environment you have set. For example, you can have different values for your settings depending on whether you're in development mode or production mode. See the chapter on Switching Environments for more details.

How to Set Configurations

To change a CFWheels application default, you generally use the set() function. With it, you can perform all sorts of tweaks to the framework's default behaviors.

How to Access Configuration Values

Use the get() function to access the value of a CFWheels application setting. Just pass it the name of the setting.

CFScript

if (get("environment") == "production") {
    // Do something for production environment
}

Setting CFML Application Configurations

In CFML's standard Application.cfc, you can normally set values for your application's properties in the thisscope. CFWheels still provides these options to you in the file at config/app.cfm.

Here is an example of what can go in config/app.cfm:

config/app.cfm

this.name = "TheNextSiteToBeatTwitter";
this.sessionManagement = false;

this.customTagPaths = ListAppend(
  this.customTagPaths,
  ExpandPath("../customtags")
);

Types of Configurations Available

There are several types of configurations that you can perform in CFWheels to override all those default behaviors. In CFWheels, you can find all these configuration options:

Environment settings
URL rewriting settings
Data source settings
Function settings
Debugging and error settings
Caching settings
ORM settings
Plugin settings
Media settings
Routing settings
View helper settings
CSRF protection settings
Miscellaneous Settings
Migrator settings

Let's take a closer look at each of these options.

Environment Settings

Not only are the environments useful for separating your production settings from your "under development" settings, but they are also opportunities for you to override settings that will only take effect in a specified environment.

The setting for the current environment can be found in config/environment.cfm and should look something like this:

config/environment.cfm

set(environment="development");

Full Listing of Environment Settings

Name

Type

Default

Description

environment

string

development

Environment to load. Set this value in config/environment.cfm. Valid values are development, testing, maintenance, and production.

reloadPassword

string

[empty string]

Password to require when reloading the CFWheels application from the URL. Leave empty to require no password.

redirectAfterReload

boolean

Enabled in maintenance and production

Whether or not to redirect away from the current URL when it includes a reload request. This hinders accidentally exposing your application's reload URL and password in web analytics software, screenshots of the browser, etc.

ipExceptions

string

[empty string]

IP addresses that CFWheels will ignore when the environment is set to maintenance. That way administrators can test the site while in maintenance mode, while the rest of users will see the message loaded in events/onmaintenance.cfm.

allowEnvironmentSwitchViaUrl

boolean

true

Set to false to disable switching of environment configurations via URL. You can still reload the application, but switching environments themselves will be disabled.

URL Rewriting Settings

Sometimes it is useful for our applications to "force" URL rewriting. By default, CFWheels will try to determinate what type of URL rewriting to perform and set it up for you. But you can force in or out this setting by using the example below:

CFScript

set(urlRewriting="Off");

The code above will tell CFWheels to skip its automatic detection of the URL Rewriting capabilities and just set it as "Off".

You can also set it to "Partial" if you believe that your web server is capable of rewriting the URL as folders after index.cfm.

For more information, read the chapter about URL Rewriting.

Data Source Settings

Probably the most important configuration of them all. What is an application without a database to store all of its precious data?

The data source configuration is what tells CFWheels which database to use for all of its models. (This can be overridden on a per-model basis, but that will be covered later.) To set this up in CFWheels, it's just as easy as the previous example:

CFScript

set(dataSourceName="yourDataSourceName");
set(dataSourceUserName="yourDataSourceUsername");
set(dataSourcePassword="yourDataSourcePassword");

Function Settings

OK, here it's where the fun begins! CFWheels includes a lot of functions to make your life as a CFML developer easier. A lot of those functions have sensible default argument values to minimize the amount of code that you need to write. And yes, you guessed it, CFWheels lets you override those default argument values application-wide.

Let's look at a little of example:

CFScript

set(functionName="findAll", perPage=20);

That little line of code will make all calls to the findAll() method in CFWheels return a maximum number of 20 record per page (if pagination is enabled for that findAll() call). How great is that? You don't need to set the perPage value for every single call to findAll() if you have a different requirement than the CFWheels default of 10 records.

Debugging and Error Settings

You'll generally want to configure how CFWheels handles errors and debugging information based on your environment. For example, you probably won't want to expose CFML errors in your production environment, whereas you would want to see those errors in your development environment.

For example, let's say that we want to enable debugging information in our "development" environment temporarily:

CFScript

// /config/development/settings.cfm
set(showDebugInformation=false);

Full Listing of Debugging and Error Settings

Name

Type

Default

Description

errorEmailServer

string

[empty string]

Server to use to send out error emails. When left blank, this defaults to settings in the ColdFusion Administrator (if set).

errorEmailAddress

string

[empty string]

Comma-delimited list of email address to send error notifications to. Only applies if sendEmailOnError is set to true.

errorEmailSubject

string

Error

Subject of email that gets sent to administrators on errors. Only applies if sendEmailOnError is set to true.

excludeFromErrorEmail

string

[empty string]

List of variables (or entire scopes) to exclude from the scope dumps included in error emails. Use this to keep sensitive information from being sent in plain text over email.

sendEmailOnError

boolean

Enabled in production environments that have a TLD like .com, .org, etc.

When set to true, CFWheels will send an email to administrators whenever CFWheels throws an error.

showDebugInformation

boolean

Enabled in development mode.

When set to true, CFWheels will show debugging information in the footers of your pages.

showErrorInformation

boolean

Enabled in development, maintenance, and testing mode.

When set to false, CFWheels will run and display code stored at events/onerror.cfm instead of revealing CFML errors.

For more information, refer to the chapter about Switching Environments.

Caching Settings

CFWheels does a pretty good job at caching the framework and its output to speed up your application. But if personalization is key in your application, finer control over caching settings will become more important.

Let's say your application generates dynamic routes and you need it to check the routes on each request. This task will be as simple as this line of code:

CFScript

set(cacheRoutes=false);

Full Listing of Caching Settings

Name

Type

Default

Description

cacheActions

boolean

Enabled in maintenance, testing, and production

When set to true, CFWheels will cache output generated by actions when specified (in a caches() call, for example).

cacheControllerConfig

boolean

Enabled in development, maintenance, testing, and production

When set to false, any changes you make to the config() function in the controller file will be picked up immediately.

cacheCullInterval

numeric

Number of minutes between each culling action. The reason the cache is not culled during each request is to keep performance as high as possible.

cacheCullPercentage

numeric

If you set this value to 10, then at most, 10% of expired items will be deleted from the cache.

cacheDatabaseSchema

boolean

Enabled in development, maintenance, testing, and production

When set to false, you can add a field to the database, and CFWheels will pick that up right away.

cacheFileChecking

boolean

Enabled in development, maintenance, testing, and production

When set to true, CFWheels will cache whether or not controller, helper, and layout files exist

cacheImages

boolean

Enabled in development, maintenance, testing, and production

When set to true, CFWheels will cache general image information used in imageTag() like width and height.

cacheModelConfig

boolean

Enabled in development, maintenance, testing, and production

When set to false, any changes you make to the config() function in the model file will be picked up immediately.

cachePages

boolean

Enabled in maintenance, testing, and production

When set to true, CFWheels will cache output generated by a view page when specified (in a renderView() call, for example).

cachePartials

boolean

Enabled in maintenance, testing, and production

When set to true, CFWheels will cache output generated by partials when specified (in a includePartial() call for example).

cacheQueries

boolean

Enabled in maintenance, testing, and production

When set to true, CFWheels will cache SQL queries when specified (in a findAll() call, for example).

clearQueryCacheOnReload

boolean

true

Set to true to clear any queries that CFWheels has cached on application reload.

cacheRoutes

boolean

Enabled in development, maintenance, testing, and production

When set to true, CFWheels will cache routes across all page views.

defaultCacheTime

numeric

Number of minutes an item should be cached when it has not been specifically set through one of the functions that perform the caching in CFWheels (i.e., caches(), findAll(), includePartial(), etc.)

maximumItemsToCache

numeric

5000

Maximum number of items to store in CFWheels's cache at one time. When the cache is full, items will be deleted automatically at a regular interval based on the other cache settings.

For more information, refer to the chapter on Caching.

ORM Settings

The CFWheels ORM provides many sensible conventions and defaults, but sometimes your data structure requires different column naming or behavior than what CFWheels expects out of the box. Use these settings to change those naming conventions or behaviors across your entire application.

For example, if we wanted to prefix all of the database table names in our application with blog_ but didn't want to include that at the beginning of model names, we would do this:

CFScript

set(tableNamePrefix="blog_");

Now your post model will map to the blog_posts table, comment model will map to the blog_comments table, etc.

Full Listing of ORM Settings

Name

Type

Default

Description

afterFindCallbackLegacySupport

boolean

true

When this is set to false and you're implementing an afterFind() callback, you need to write the same logic for both the this scope (for objects) and arguments scope (for queries). Setting this to false makes both ways use the arguments scope so you don't need to duplicate logic. Note that the default is true for backwards compatibility.

automaticValidations

boolean

true

Set to false to stop CFWheels from automatically running object validations based on column settings in your database.

setUpdatedAtOnCreate

boolean

true

Set to false to stop CFWheels from populating the updatedAt timestamp with the createdAt timestamp's value.

softDeleteProperty

string

deletedAt

Name of database column that CFWheels will look for in order to enforce soft deletes.

tableNamePrefix

string

[empty string]

String to prefix all database tables with so you don't need to define your model objects including it. Useful in environments that have table naming conventions like starting all table names with tbl

timeStampOnCreateProperty

string

createdAt

Name of database column that CFWheels will look for in order to automatically store a "created at" time stamp when records are created.

timeStampOnUpdateProperty

string

updatedAt

Name of the database column that CFWheels will look for in order to automatically store an "updated at" time stamp when records are updated.

transactionMode

string

commit

Use commit, rollback, or none to set default transaction handling for creates, updates and deletes.

useExpandedColumnAliases

boolean

false

When set to true, CFWheels will always prepend children objects' names to columns included via findAll()'s include argument, even if there are no naming conflicts. For example, model("post").findAll(include="comment") in a fictitious blog application would yield these column names: id, title, authorId, body, createdAt, commentID, commentName, commentBody, commentCreatedAt, commentDeletedAt. When this setting is set to false, the returned column list would look like this: id, title, authorId, body, createdAt, commentID, name, commentBody, commentCreatedAt, deletedAt.

modelRequireConfig

boolean

false

Set to true to have CFWheels throw an error when it can't find a config() method for a model. If you prefer to always use config() methods, this setting could save you some confusion when it appears that your configuration code isn't running due to misspelling "config" for example.

Plugin Settings

There are several settings that make plugin development more convenient. We recommend only changing these settings in development mode so there aren't any deployment issues in production, testing, and maintenancemodes. (At that point, your plugin should be properly packaged in a zip file.)

If you want to keep what's stored in a plugin's zip file from overwriting changes that you made in its expanded folder, set this in config/development/settings.cfm:

CFScript

set(overwritePlugins=false);

See the chapter on Installing and Using Plugins for more information.

Name

Type

Default

Description

deletePluginDirectories

boolean

true

When set to true, CFWheels will remove subdirectories within the plugins folder that do not contain corresponding plugin zip files. Set to false to add convenience to the process for developing your own plugins.

loadIncompatiblePlugins

boolean

true

Set to false to stop CFWheels from loading plugins whose supported versions do not match your current version of CFWheels.

overwritePlugins

boolean

true

When set to true, CFWheels will overwrite plugin files based on their source zip files on application reload. Setting this to false makes plugin development easier because you don't need to keep rezipping your plugin files every time you make a change.

showIncompatiblePlugins

boolean

false

When set to true, an incompatibility warning will be displayed for plugins that do not specify the current CFWheels version.

Media Settings

Configure how CFWheels handles linking to assets through view helpers like imageTag(), styleSheetLinkTag(), and javaScriptIncludeTag().

See the chapter about Date, Media, and Text Helpers for more information.

Full Listing of Asset Settings

Name

Type

Default

Description

assetQueryString

boolean

false in development mode, true in the other modes

Set to true to append a unique query string based on a time stamp to JavaScript, CSS, and image files included with the media view helpers. This helps force local browser caches to refresh when there is an update to your assets. This query string is updated when reloading your CFWheels application. You can also hard code it by passing in a string.

assetPaths

struct

false

Pass false or a struct with up to 2 different keys to autopopulate the domains of your assets: http (required) and https. For example: {http="asset0.domain1.com,asset2.domain1.com,asset3.domain1.com", https="secure.domain1.com"}

Routing Settings

CFWheels includes a powerful routing system. Parts of it are configurable with the following settings.

See the chapters about Using Routes and Obfuscating URLs for more information about how this all works together.

Full Listing of Miscellaneous Settings

Name

Type

Default

Description

loadDefaultRoutes

boolean

true

Set to false to disable CFWheels's default route patterns for controller/action/key, etc.

obfuscateUrls

boolean

false

Set to true to obfuscate primary keys in URLs.

View Helper Settings

CFWheels has a multitude of view helpers for building links, forms, form elements, and more. Use these settings to configure global defaults for their behavior.

Name

Type

Default

Description

booleanAttributes

any

allowfullscreen, async, autofocus, autoplay, checked, compact, controls, declare, default, defaultchecked, defaultmuted, defaultselected, defer, disabled, draggable, enabled, formnovalidate, hidden, indeterminate, inert, ismap, itemscope, loop, multiple, muted, nohref, noresize, noshade, novalidate, nowrap, open, pauseonexit, readonly, required, reversed, scoped, seamless, selected, sortable, spellcheck, translate, truespeed, typemustmatch, visible

A list of HTML attributes that should be allowed to be set as boolean values when added to HTML tags (e.g. disabled instead of disabled="disabled"). You can also pass in true(all attributes will be boolean) or false (no boolean attributes allowed, like in XHTML).

CSRF Protection Settings

CFWheels includes built-in Cross-Site Request Forgery (CSRF) protection for form posts. Part of the CSRF protection involves storing an authenticity token in the session (default) or within an encrypted cookie. Most of the settings below are for when you've chosen to store the authenticity token within a cookie instead of the server's session store.

Name

Type

Default

Description

csrfStore

string

session

Which storage strategy to use for storing the CSRF authenticity token. Valid values are session or cookie. Choosing session requires no additional configuration. Choosing cookie for this requires additional configuration listed below.

csrfCookieEncryptionAlgorithm

string

AES

Encryption algorithm to use for encrypting the authenticity token cookie contents. This setting is ignored if you're using session storage. See your CF engine's documentation for the Encrypt()function for more information.

csrfCookieEncryptionSecretKey

string

Secret key used to encrypt the authenticity token cookie contents. This value must be configured to a string compatible with the csrfCookieEncryptionAlgorithmsetting if you're using cookie storage. This value is ignored if you're using session storage. See your CF engine's documentation for the Encrypt()function for more information.

csrfCookieEncryptionEncoding

string

Base64

Encoding to use to write the encrypted value to the cookie. This value is ignored if you're using session storage. See your CF engine's documentation for the Encrypt() function for more information.

csrfCookieName

string

_wheels_authenticity

The name of the cookie to be set to store CSRF token data. This value is ignored if you're using session storage.

csrfCookieDomain

string

Domain to set the cookie on. See your CF engine's documentation for cfcookie for more information.

csrfCookieEncodeValue

boolean

Whether or not to have CF encode the cookie. See your CF engine's documentation for cfcookie for more information.

csrfCookieHttpOnly

boolean

true

Whether or not the have CF set the cookie as HTTPOnly. See your CF engine's documentation for cfcookie for more information.

csrfCookiePath

string

Path to set the cookie on. See your CF engine's documentation for cfcookie for more information.

csrfCookiePreserveCase

boolean

Whether or not to preserve the case of the cookie's name. See your CF engine's documentation for cfcookie for more information.

csrfCookieSecure

boolean

Whether or not to only allow the cookie to be delivered over the HTTPS protocol. See your CF engine's documentation for cfcookie for more information.

CORS Protection Settings

CFWheels includes built-in Cross-Origin Resource Sharing (CORS) which allows you to configure which cross-origin requests and methods are allowed. By default, this feature is turned off which will deny cross origin requests at the browser level.

In this first version, the user can enable this feature, which will allow requests from all origins and all methods.

Name

Type

Default

allowCorsRequests

boolean

false

Miscellaneous Settings

Name

Type

Default

Description

disableEngineCheck

boolean

false

Set to true if you don't want CFWheels to block you from using older CFML engines (such as ColdFusion 9, Railo etc).

enableMigratorComponent

boolean

true

Set to false to completely disable the migrator component which will prevent any Database migrations

enablePluginsComponent

boolean

true

Set to false to completely disable the plugins component which will prevent any plugin loading, and not load the entire plugins system

enablePublicComponent

boolean

true

Set to false to completely disable the public component which will disable the GUI even in development mode

Migrator Configuration Settings

Setting

Type

Default

Description

autoMigrateDatabase

Boolean

false

Automatically runs available migration on applicationstart.

migratorTableName

String

migratorversions

The name of the table that stores the versions migrated.

createMigratorTable

Boolean

true

Create the migratorversions database table.

writeMigratorSQLFiles

Boolean

false

Writes the executed SQL to a .sql file in the /migrator/sql directory.

migratorObjectCase

String

lower

Specifies the case of created database object. Options are 'lower', 'upper' and 'none' (which uses the given value unmodified)

allowMigrationDown

Boolean

false (true in development mode)

Prevents 'down' migrations (rollbacks)

Form Helpers and Showing Errors

CFWheels ties your application's forms together with your model layer elegantly. With CFWheels form conventions, you'll find yourself spending less time writing repetitive markup.

The majority of applications are not all about back-end. There is a great deal of work to perform on the front-end as well. It can be argued that most of your users will think of the interface as the application.

CFWheels is here to take you to greener pastures with its form helper functions. Let's get visual with some code examples.

Simple Example: The Old Way

Here is a simple form for editing a user profile. Normally, you would code your web form similarly to this:

views/profiles/edit.cfm

<cfoutput>

<form action="/profile" method="post">
    <div>
        <label for="firstName">First Name</label>
        <input id="firstName" name="firstName" value="#EncodeForHtml(profile.firstName)#">
    </div>

    <div>
        <label for="lastName">Last Name</label>
        <input id="lastName" name="lastName" value="#EncodeForHtml(profile.lastName)#">
    </div>

    <div>
        <label for="department">Department</label>
        <select id="department" name="departmentId">
            <cfloop query="departments">
                <option
                    value="#EncodeForHtml(departments.id)#"
                    <cfif profile.departmentId eq departments.id>
                        selected
                    </cfif>
                >#EncodeForHtml(departments.name)#</option>
            </cfloop>
        </select>
    </div>

    <div>
        <input type="submit" value="Save Changes">
    </div>
</form>

</cfoutput>

Then you would write a script for the form that validates the data submitted, handles interactions with the data source(s), and displays the form with errors that may happen as a result of user input. (And most of that code isn't even included in this example.)

We know that you are quite familiar with the drudgery of typing this sort of code over and over again. Let's not even mention the pain associated with debugging it or adding new fields and business logic!

Making Life Easier: CFWheels Form Helpers

The good news is that CFWheels simplifies this quite a bit for you. At first, it looks a little different using these conventions. But you'll quickly see how it all ties together and saves you some serious time.

Rewriting the Form with CFWheels Conventions

Let's rewrite and then explain.

views/profiles/edit.cfm

<cfoutput>

#startFormTag(route="profile", method="patch")#
    #textField(
        label="First Name",
        objectName="profile",
        property="firstName",
        prependToLabel="<div>",
        append="</div>",
        labelPlacement="before"
    )#

    #textField(
        label="Last Name",
        objectName="profile",
        property="lastName",
        prependToLabel="<div>",
        append="</div>",
        labelPlacement="before"
    )#

    #select(
        label="Department",
        objectName="profile",
        property="departmentId",
        options=departments,
        prependToLabel="<div>",
        append="</div>",
        labelPlacement="before"
    )#

    <div>
        #submitTag()#
    </div>
#endFormTag()#

</cfoutput>

I know what you are thinking. 9 lines of code can't replace all that work, right? In fact, they do. The HTML output will be very nearly the same as the previous example. By using CFWheels conventions, you are saving yourself a lot of key strokes and a great deal of time.

Linking up the Form's Action with startFormTag

The first helper you'll notice in the CFWheels-ified version of the form is startFormTag(). This helper allows you to easily link up the form to the action that it's posting to in a secure way.

You'll need to configure the route and method arguments, depending on the route that you're sending the form to. Also, if the route expects any parameters, you must pass those in as arguments to startFormTag as well. If you haven't already, read up about routes in the Routing chapter.

As we said, when linking a form to a route, there are 3 pieces of information that you will need to work with:

Route name
Parameters that the route may expect
Request method that the route requires

Use Routes for Form Posts

CFWheels's default wildcard controller/action-based URLs will not accept form posts for security reasons. This is due to an attack known as Cross Site Request Forgery (CSRF). We strongly recommend configuring routes to post your forms to.

Most of the time, you'll probably be working with a resource. Your config/routes.cfm may look something like this:

config/routes.cfm

mapper()
    .resources("users")
.end();

If you click the View Routes link in the debug footer, you'll be most interested in these types of routes for your forms:

Name

Method

Pattern

Controller

Action

users

GET

/users

users

index

users

POST

/users

users

create

user

PATCH

/users/[key]

users

update

user

DELETE

/users/[key]

users

delete

Once you get to this list of routes, it really doesn't matter how you authored them in your config/routes.cfm. What matters is that you know the names, methods, and parameters that the routes expect. (With some practice, you'll probably be able to look at config/routes.cfm and know exactly what the names, methods, and parameters are though.)

If you are creating a record, your route is likely setup to accept a POST method. That happens to be the default for startFormTag(), so you don't even need to include the method argument. You can then pass the users route name to the route argument:

views/users/new.cfm

<!--- `method` argument defaults to `post`, so we don't need to pass it in. --->
#startFormTag(route="users")#
#endFormTag()

If you need to send the form via another HTTP method, you can pass that in for the method argument as listed in your routes:

<!---
    Search forms typically are done via `get` requests. This one is to
    the index. --->
#startFormTag(route="users", method="get")#
    #textFieldTag(type="search", name="q")#
    #submitTag("Search")#
#endFormTag()#

<!--- Update forms typically are sent via `patch` requests. --->
#startFormTag(route="user", key=user.key(), method="patch")#
    #textField(objectName="user", property="firstName")#
    #submitTag()#
#endFormTag()#

<!---
    Delete requests are best done via a form post, even if you're styling the
    form to look like a link.
--->
#startFormTag(
    route="user",
    key=user.key(),
    method="delete",
    class="inline-form"
)#
    #buttonTag(content="Delete User", class="link-button")#
#endFormTag()#

Notice above that the user route expects a key parameter, so that is passed into startFormTag as the keyargument.

To drive the point home about routing parameters, let's say that we have this route:

Name

Method

Pattern

Controller

Action

productVariation

PATCH

[language]/products/[productKey]/variations/[key]

variations

update

As you can see, the parameters can be anything, not just primary keys.

You would link up the form like so:

#startFormTag(
    route="productVariation",
    language="es",
    productKey=product,key(),
    key=variation.key(),
    method="patch"
)#
    <!--- ... --->
#endFormTag()

A Note About PATCH and DELETE Requests

Browsers (even the modern ones) tend to only work well with GET and POST requests, so how does CFWheels also enable PATCH and DELETE requests?

To keep things secure, CFWheels will still use method="post" on the form to send PATCH and DELETE requests. But the CFWheels router will recognize a PATCH or DELETE request if a form variable called _method is also sent, specifying the PATCH or DELETE method.

Under the hood, startFormTag() will also generate a hidden field called _method that passes the request method along with the form POST.

So the <form> tag generated along with a method of patch will look something like this:

<form action="/users/1234" method="post">
    <input type="hidden" name="_method" value="patch">
    <input type="hidden" name="authenticityToken" value="cxRbrHAnwpG0Ki9vTYW4yg==">
</form>

You'll notice that startFormTag() will also add another hidden field along with POSTed requests called authenticityToken, which helps prevent against Cross-Site Request Forgery (CSRF) attacks.

The moral of the story: startFormTag() takes care of all of this for you. If you for some reason decide to wire up your own custom <form> tag that must POST data, be sure to add your own hidden fields for _method and use the authenticityTokenField() helper to generate the hidden field for the authenticityToken that CFWheels will require on the POST.

Refactoring Common Settings with Global Defaults

By setting up global defaults (as explained in the Configuration and Defaults) for the prependToLabel, append, and labelPlacement arguments, you can make the form code ever simpler across your whole application.

Here are the settings that you would apply in config/settings.cfm:

config/settings.cfm

set(
    functionName="textField",
    prependToLabel="<div>",
    append="</div>",
    labelPlacement="before"
);

set(
    functionName="select",
    prependToLabel="<div>",
    append="</div>",
    labelPlacement="before"
);

And here's how our example code can be simplified as a result:

views/profiles/edit.cfm

<cfoutput>

#startFormTag(route="profile", method="patch")#
    #textField(label="First Name", objectName="profile", property="firstName")#
    #textField(label="Last Name", objectName="profile", property="lastName")#

    #select(
        label="Department",
        objectName="profile",
        property="departmentId",
        options=departments
    )#

    <div>
        #submitTag()#
    </div>
#endFormTag()#

</cfoutput>

All that the controller needs to provide at this point is a model object instance named profile that contains firstName, lastName, and departmentId properties and a query object named departments that contains identifier and text values. Note that the instance variable is named profile, though the model itself doesn't necessarily need to be named profile.

If you pass the form an empty instance named profile (for example, created by new(), the form will display blank values for all the fields. If you pass it an object created by a finder like findOne() or findByKey(), then the form will display the values provided through the object. This allows for us to potentially use the same view file for both create and update scenarios in our application.

Refactoring Label Names

If you look at the previous examples, there is one other bit of configuration that we can clean up: the label arguments passed to textField() and select().

Because we've named firstName, lastName, and departmentId in conventional ways (camel case), CFWheels will generate the labels for us automatically:

views/profiles/edit.cfm

<cfoutput>

#startFormTag(route="profile", method="patch")#
    #textField(objectName="profile", property="firstName")#
    #textField(objectName="profile", property="lastName")#

    #select(
        objectName="profile",
        property="departmentId",
        options=departments
    )#

    <div>
        #submitTag()#
    </div>
#endFormTag()#

</cfoutput>

You'll notice that CFWheels is even smart enough to translate the departmentId property to Department.

If you ever need to override a label, you can do so in the model's initializer using the label argument of the property()method:

models/User.cfc

component extends="Model" {
    function init() {
        property(name="lastName", label="Surname");
    }
}

Form Error Messages

If you really want to secure a form, you need to do it server side. Sure, you can add JavaScript here and there to validate your web form. Unfortunately, disabling JavaScript (and thus your JavaScript-powered form validation) is simple in web browsers, and malicious bots tend not to listen to JavaScript.

Securing the integrity of your web forms in CFWheels on the server side is very easy. Assuming that you have read the chapter on Object Validation, you can rest assured that your code is a lot more secure now.

Displaying a List of Model Validation Errors

CFWheels provides you with a tool set of Helper Functions just for displaying error messages as well.

In the controller, let's say that this just happened. Your model includes validations that require the presence of both firstName and lastName. The user didn't enter either. So in the controller's update action, it loads the model object, sets the values that the user submitted, sees that there was a validation error after calling update(), and displays the form view again.

The update action may look something like this:

controllers/Profiles.cfc

function update() {
    // In this example, we're loading an existing object based on the user's
    // session.
    profile = model("user").findByKey(session.userId);

    // If everything validated, then send user to success message
    if (profile.update(params.profile)) {
        flashInsert(success="Profile updated.");
    }
    // If there were errors with the form submission, show the form again
    // with errors.
    else {
        flashInsert(error="There was an error with your changes.");
        renderView(action="edit");
    }
}

Notice that the view for the edit action is rendered if the profile object's update() returns false.

Let's take the previous form example and add some visual indication to the user about what he did wrong and where, by simply adding the following code on your form page.

views/profiles/edit.cfm

<cfoutput>

#errorMessagesFor("profile")#

#startFormTag(route="profile", method="patch")#
    #textField(objectName="profile", property="firstName")#
    #textField(objectName="profile", property="lastName")#

    #select(
        objectName="department",
        property="departmentId",
        options=departments
    )#

    <div>
        #submitTag()#
    </div>
#endFormTag()#

</cfoutput>

How about that? With just that line of code (and the required validations on your object model), CFWheels will do the following:

Generate an HTML unordered list with a HTML class name of errorMessages.
Display all the error messages on your profile object as list items in that unordered list.
Wrap each of the erroneous fields in your form with a surrounding <div class="fieldWithErrors"> HTML tag for you to enrich with your ninja CSS skills.

There is no longer the need to manually code error logic in your form markup.

Showing Individual Fields' Error Messages

Let's say that would rather display the error messages just below the failed fields (or anywhere else, for that matter). CFWheels has that covered too. All that it takes is a simple line of code for each form field that could end up displaying feedback to the user.

Let's add some error message handlers for the firstName, lastName, and departmentId fields:

views/profiles/edit.cfm

<cfoutput>

#startFormTag(route="profile", method="patch")#
    #textField(objectName="profile", property="firstName")#
    #errorMessageOn(objectName="profile", property="firstName")#

    #textField(objectName="profile", property="lastName")#
    #errorMessageOn(objectName="profile", property="lastName")#

    #selectTag(
        objectName="profile",
        property="departmentId",
        options=departments
    )#
    #errorMessageOn(objectName="profile", property="departmentId")#

    <div>
        #submitTag()#
    </div>
#endFormTag()#

</cfoutput>

Notice the call to the errorMessageOn() function below the firstName, lastName, and departmentId fields. That's all it takes to display the corresponding error messages of each form control on your form.

And the error messages won't even display if there aren't any. That way you can yet again use the same form code for error and non-error scenarios alike.

Types of Form Helpers

There is a CFWheels form helper for basically every type of form element available in HTML. And they all have the ability to be bound to CFWheels model instances to make displaying values and errors easier. Here is a brief description of each helper.

Text, Password, and TextArea Fields

Text and password fields work similarly to each other. They allow you to show labels and bind to model object instances to determine whether or not a value should be pre-populated.

#textField(objectName="user", property="username")#
#passwordField(objectName="user", property="password")#
#textArea(objectName="user", property="biography", rows=5, cols=40)#

May yield the equivalent to this HTML (if we assume the global defaults defined above in the section named Factoring out Common Settings with Global Defaults):

<div>
    <label for="user-username">Username</label>
    <input id="user-username" type="text" name="user[username]" value="cfguy">
</div>
<div>
    <label for="user-password">Password</label>
    <input id="user-password" type="password" name="user[password]" value="">
</div>
<div>
    <label for="user-biography">Bio</label>
    <textarea id="user-biography" name="user[biography]">
        CF Guy really is a great guy. He's much nicer than .NET guy.
    </textarea>
</div>

Hidden Fields

Hidden fields are powered by the hiddenField() form helper, and it also works similarly to textField() and passwordField().

#hiddenField(objectName="user", property="referralSourceId")#

Would yield this type of markup:

<input type="hidden" name="user[referralSourceId]" value="425">

Select Fields

As hinted in our first example of form helpers, the select() function builds a <select> list with options. What's really cool about this helper is that it can populate the <option>s with values from a query, struct, or array.

Take a look at this line:

#select(objectName="user", property="departmentId", options=departments)#

Assume that the departments variable passed to the options argument contains a query, struct, or array of department data that should be selectable in the drop-down.

Each data type has its advantages and disadvantages:

Queries allow you to order your results, but you can only use one column. But this can be overcome using Calculated Properties.
Structs allow you to build out static or dynamic values using whatever data that you please, but there is no guarantee that your CFML engine will honor the order in which you add the elements.
Arrays also allow you to build out static or dynamic values, and there is a guarantee that your CFML engine will honor the order. But arrays are a tad more verbose to work with.

CFWheels will examine the data passed to options and intelligently pick out elements to populate for the <option>s' values and text.

Query: CFWheels will try to pick out the first numeric column for value and the first non-numeric column for the display text. The order of the columns is determined how you have them defined in your database.
Struct: CFWheels will use the keys as the value and the values as the display text.
Array: CFWheels will react depending on how many dimensions there are. If it's only a single dimension, it will populate both the value and display text with the elements. When it's a 2D array, CFWheels will use each item's first element as the value and each element's second element as the display text. For anything larger than 2 dimensions, CFWheels only uses the first 2 sub-elements and ignores the rest.

Here's an example of how you might use each option:

// Query generated in your controller --->
departments = findAll(orderBy="name");

// Hard-coded struct set up in events/onapplicationstart.cfm
application.departments["1"] = "Sales";
application.departments["2"] = "Marketing";
application.departments["3"] = "Information Technology";
application.departments["4"] = "Human Resources";

// Array built from query call in model
departments = this.findAll(orderBy="lastName,hq");

departmentsArray = [];

for (department in departments) {
    ArrayAppend(
        departmentsArray,
        [department.id, "#department.name# - #department.hq#"]
    );
}

When sending a query, if you need to populate your <option>s' values and display text with specific columns, you should pass the names of the columns to use as the textField and valueField arguments.

You can also include a blank option by passing true or the desired text to the includeBlank argument.

Here's a full usage with this new knowledge:

#select(
    objectName="user",
    property="departmentId",
    options=departments,
    valueField="id",
    textField="departmentName",
    includeBlank="Select a Department"
)#

Radio Buttons

Radio buttons via radioButton() also take objectName and property values, and they accept an argument called tagValue that determines what value should be passed based on what the user selects.

Here is an example using a query object called eyeColor to power the possible values:

<fieldset>
    <legend>Eye Color</legend>

    <cfloop query="eyeColor">
        #radioButton(
            label=eyeColor.color,
            objectName="profile",
            property="eyeColorId",
            tagValue=eyeColor.id,
            labelPlacement="after"
        )#<br>
    </cfloop>
</fieldset>

If the profile object already has a value set for eyeColorId, then radioButton() will make sure that that value is checked on page load.

If profile.eyeColorId's value were already set to 1, the rendered HTML would appear similar to this:

<fieldset>
    <legend>Eye Color</legend>

    <input
        type="radio"
        id="profile-eyeColorId-2"
        name="profile[eyeColorId]"
        value="2"
    >
    <label for="profile-eyeColorId-2">Blue</label><br>

    <input
        type="radio"
        id="profile-eyeColorId-1"
        name="profile[eyeColorId]"
        value="1"
        checked="checked"
    >
    <label for="profile-eyeColorId-1">Brown</label><br>

    <input
        type="radio"
        id="profile-eyeColorId-3"
        name="profile[eyeColorId]"
        value="3"
    >
    <label for="profile-eyeColorId-3">Hazel</label><br>
</fieldset>

Note that if you don't specify labelPlacement="after" in your calls to radioButton(), CFWheels will place the labels before the form controls.

Check Boxes

Check boxes work similarly to radio buttons, except checkBox() takes parameters called checkedValue and uncheckedValue to determine whether or not the check box should be checked on load.

Note that binding check boxes to model objects is best suited for properties in your object that have a yes/no or true/false type value.

#checkBox(
    label="Sign me up for the email newsletter.",
    objectName="customer",
    property="newsletterSubscription",
    labelPlacement="after"
)#

Because the concept of check boxes don't tie too well to models (you can select several for the same "property"), we recommend using checkBoxTag() instead if you want to use check boxes for more values than just true/false. See the Helpers That Aren't Bound to Model Objects section below.

File Fields

The fileField() helper builds a file field form control based on the supplied objectName and property.

#fileField(label="Photo", objectName="profile", property="photo")#

In order for your form to pass the correct enctype, you can pass multipart=true to startFormTag():

#startFormTag(route="attachments", multipart=true)#

Setting a Default Value on an Object-bound Field

Looking at this form code, it isn't 100% evident how to set an initial value for the fields:

views/accounts/new.cfm

#startFormTag(route="accounts")#
    #textField(objectName="account", property="title")#
    #select(objectName="account", property="accountTypeId")#
    #checkBox(objectName="account", property="subscribedToNewsletter")#
#endFormTag()#

What if we want a random title pre-filled, a certain account type pre-selected, and the check box automatically checked when the form first loads?

The answer lies in the account object that the fields are bound to. Let's say that you always wanted this behavior to happen when the form for a new account loads. You can do something like this in the controller:

controllers/Accounts.cfc

component extends="controllers.Controller" {
    function new() {
        local.defaultAccountType = model("accountType").findOne(
          where="isDefault=1"
        );

        account = model("account").new(
            title=generateRandomTitle(),
            accountTypeId=local.defaultAccountType.key(),
            subscribedToNewsletter=true
        );
    }
}

Now the initial state of the form will reflect the default values setup on the object in the controller.

Helpers That Aren't Bound to Model Objects

Sometimes you'll want to output a form element that isn't bound to a model object.

A search form that passes the user's query as a variable in the URL called q is a good example. In this example case, you would use the textFieldTag() function to produce the <input> tag needed.

#textFieldTag(label="Search", name="q", value=params.q)#

There are "tag" versions of all of the form helpers that we've listed in this chapter. As a rule of thumb, add Tag to the end of the function name and use the name and value, checked, and selected arguments instead of the objectName and property arguments that you normally use.

Here is a list of the "tag" helpers for your reference:

Passing Extra Arguments for HTML Attributes

Much like CFWheels's linkTo() function, any extra arguments that you pass to form helpers will be passed to the corresponding HTML tag as attributes.

For example, if we wanted to define a class on our starting form tag, we just pass that as an extra argument to startFormTag():

#startFormTag(route="posts", class="login-form")#

Which would produce this HTML:

<form action="/posts" method="post" class="login-form">

When a form helper creates more than one HTML element you can typically pass in extra arguments to be set on that element as well. One common example of this is when you need to set a class for a label element; you can do so by passing in labelClass="class-name". CFWheels will detect that your argument starts with "label" and assume it should go on the label element and not the input element (or whatever "main" element the form helper creates). This means you could also pass in labelId="my-id" to set the id on the label for example.

Boolean Attributes

HTML includes many boolean attributes like novalidate, disabled, required, etc.

If you want for a CFWheels view helper to render one of these attributes, just pass the name of the attribute as an extra argument, set it to true, and CFWheels will include the boolean attribute:

#textField(objectName="post", property="title", required=true)#
-> <input type="text" name="post[title]" value="" required>

HTML5 data Attributes

data attributes in HTML usually look something like this:

<input type="submit" value="Submit" data-ajax-url="/contacts/send.js">

Because ColdFusion arguments cannot contain any hyphens, we have constructed a workaround for you for CFWheels view helpers.

Let's say you want a data-ajax-url HTML attribute as depicted above. All you need to do is pass in an argument named dataAjaxUrl, and CFWheels will convert that attribute name to the hyphenated version in the HTML output.

#submitTag(
    value="Submit",
    dataAjaxUrl=urlFor(route="contactsSend", format="js")
)#
-> <input type="submit" value="Submit" data-ajax-url="/contacts/send.js">

As an alternative, you can pass in data_ajax_url instead if you prefer underscores, and it will produce the same result.

Special Form Helpers

CFWheels provides a few extra form helpers that make it easier for you to generate accessible fields for dates and/or times. These also bind to properties that are of type DATE, TIMESTAMP, DATETIME, etc.

We won't go over these in detail, but here is a list of the date and time form helpers available:
